SN74LV1T34DCKRG4, Translation - Voltage Levels Single Power Supply BUFFER Logic Level Shifter (no enable) 5-SC70

Semiconductors\Logic ICs\Translation - Voltage LevelsSN74LV1T34/SN74LV1T34-Q1 Logic Level ShifterTexas Instruments SN74LV1T34/SN74LV1T34-Q1 Buffer Logic Level Shifter is a low-voltage CMOS gate logic that operates at a wider voltage range for industrial, portable, and telecom applications. The output level is referenced to the supply voltage and is able to support 1.8V/2.5V/3.3V/5V CMOS levels. The input is designed with a lower threshold circuit to match 1.8V input logic at V CC = 3.3V and can be used in 1.8V to 3.3V level-up translation. In addition, the 5V tolerant input pins enable down translation (e.g. 3.3V to 2.5V output at V CC = 2.5V). The wide V CC range of 1.8V to 5.5V allows the generation of desired output levels to connect to controllers or processors. The SN74LV1T34-Q1 devices are AEC-Q100 qualified for automotive applications.
