Name: Solid state relay, 530 VAC, momentary switching, 3-32 VDC, 40 A, PCB mounting, D4840-10
Brand: Crydom
SKU: D4840-10

Кнопки, переключатели, разъемы, реле Реле Твердотельные Crydom Solid state relay, 530 VAC, momentary ...

Подробное описание

16 160 ₽

– +

Бонус: 323.2 !

Бонусная программа

Итого: 16 160 ₽

Купить

Electromechanics\RelaysSolid State SPST-NO (1 Form A) Hockey Puck

Информация о производителе
Производитель	Crydom
Бренд	Crydom
Основные
circuit	SPST-NO (1 Form A)
control voltage range:	4 VDC to 32 VDC
Дата загрузки	13.04.2024
eccn	EAR99
factory pack quantity: factory pack quantity:	40
htsus	8536.49.0080
input current:	7 mA to 12 mA
ip rating:	IP00
категория	Кнопки, переключатели, разъемы, реле/Реле
load current	40A
load current rating:	40 A
load voltage rating:	48 VAC to 530 VAC
manufacturer:	Sensata
maximum operating temperature:	+80 C
minimum operating temperature:	-40 C
moisture sensitivity level (msl)	Not Applicable
mounting style:	Panel Mount
mounting type	Chassis Mount
other related documents	http://www.crydom.com/en/service/ce_declaration_of
output type	AC
output type:	SCR
package	Bulk
package / case	Hockey Puck
партномер	8026541660
product:	Solid State Relays
product category:	Solid State Relays-Industrial Mount
product type:	SSR-Solid State Relays
relay contact form:	1 Form A(SPST-NO)
rohs status	RoHS Compliant
series	D48 ->
subcategory:	Relays
termination style	Screw Terminal
type:	Heavy Duty
voltage - input	3 ~ 32VDC
voltage - load	80V ~ 530V
