| Информация о производителе | |
| Производитель | Omron |
| Бренд | Omron |
| Основные | |
| circuit | SPST-NC (1 Form B) |
| circuit arrangement | 1 Form B |
| contact configuration | SPST |
| contact form | SPST(1 Form B) |
| contact form: | SPST(1 Form B) |
| control voltage range | 1 V to 1.3 V |
| control voltage range: | 1 VDC to 1.3 VDC |
| Дата загрузки | 13.04.2024 |
| eccn | EAR99 |
| eccn (us) | ear99 |
| eu rohs | compliant |
| factory pack quantity | 100 |
| factory pack quantity: factory pack quantity: | 400 |
| форма контакта | SPST-NC(1 Form B) |
| hts | 8542.39.00.01 |
| htsus | 8536.49.0055 |
| input current | 50 mA |
| input current: | 50 mA |
| input to output isolation method | Optocoupler |
| input to output isolation method: | Optocoupler |
| input type | DC |
| input voltage: | 1.3 V |
| i/o isolation voltage (v) | 1500(RMS) |
| категория | Кнопки, переключатели, разъемы, реле/Реле |
| клеммы реле | Gull Wing |
| конфигурация контакта | SPST-NC |
| lead shape | Gull-wing |
| линейка продукции | G3VM |
| load current | 120mA |
| load current rating | 120 mA |
| load current rating: | 120 mA |
| load voltage range | 0 → 350V ac |
| load voltage rating | 350 V |
| load voltage rating: | 350 VAC, 350 VDC |
| максимальное напряжение нагрузки | 350В |
| максимальный ток утечки выключенного состояния | 1мкА |
| макс. сопротивление включенного состояния | 25Ом |
| manufacturer | OMRON |
| manufacturer: | Omron |
| maximum control voltage | 1.3 V |
| maximum input current (ma) | 25 |
| maximum input voltage (v) | 01.03.2024 |
| maximum load current | 90 mA |
| maximum load voltage | 350 V |
| maximum off-state leakage current (ua) | 1 |
| maximum operating temperature | +85°C |
| maximum operating temperature: | +85 C |
| maximum operating temperature (°c) | 85 |
| maximum output current (a) | 0.12 |
| maximum output voltage (v) | 350 |
| maximum turn-off time (ms) | 3 |
| maximum turn-on time (ms) | 1 |
| minimum input voltage (v) | 1 |
| minimum load current | 90 mA |
| minimum load current (ma) | 120 |
| minimum operating temperature | -40°C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| монтаж реле | SMD(Поверхностный Монтаж) |
| mounting | surface mount |
| mounting style | SMD/SMT |
| mounting style: | PCB Mount |
| mounting type | Surface Mount |
| напряжение изоляции | 1.5кВ |
| on-state resistance (max) | 25 Ohms |
| operating temperature range | -40 →+85°C |
| output device | MOSFET |
| output type | AC|DC |
| output type: | MOSFET |
| package | Tube |
| package / case | 4-SOP (0.173"", 4.40mm) |
| package/case: | SOP-4 |
| package height | 1.9(Max) |
| package length | 03.09.2024 |
| package style | SOP4 |
| package width | 04.04.2024 |
| packaging | Stick |
| packaging: | Tube |
| партномер | 8004263470 |
| part # aliases | G3VM353GNC |
| part # aliases: | G3VM353G |
| part status | active |
| pcb changed | 4 |
| pin count | 4 |
| product | Power Relays |
| product: | Solid State Relays |
| product category | Solid State Relays-PCB Mount |
| product category: | Solid State Relays-PCB Mount |
| product type: | SSR-Solid State Relays |
| прямой ток | 25мА |
| relay contact form: | 1 Form B(SPST-NC) |
| rohs | Details |
| rohs status | RoHS Compliant |
| series | G3VM -> |
| series: | G3VM |
| standard package name | SOP |
| стиль корпуса моп-транзисторного реле | SOP-4 |
| subcategory: | Relays |
| supplier device package | 4-SOP |
| supplier package | SOP |
| terminal type | PCB Pin |
| termination style | Gull Wing |
| termination style: | SMD/SMT |
| типовая емкость i/o | 0.8пФ |
| тип нагрузки | AC/DC |
| ток нагрузки | 120мА |
| type: | High Current |
| typical input to output capacitance (pf) | 0.8 |
| вес, г | 0.2 |
| voltage - input | 1.15VDC |
| voltage - load | 0V ~ 350V |
