ST2-DC12V-F, General Purpose Relays 8A 12VDC DPST NON-LATCHING PCB

The ST2-DC12V-F is a polarized Power Relay with DC coil. This ST-series power relay has 2 form-A Au-flashed AgSnO2 contacts. High contact pressure, low contact bounce and forced separation structure that radically improves resistance to contact welding. High breakdown voltage has been achieved, between contacts and coil of 3750Vrms. Surge breakdown voltage between coil and contact of 6000V and between open contact of 1200Vrms mean that these relays are suitable even for 250V power circuit control. • Single side stable function• Even with small form factor, sensitive enough for direct IC-driving• High switching capability• High breakdown voltage• Automatic cleaning possible• Easy to design PC board patterns
