G2RL-1A-E-CV DC24, Универсальное реле, серия G2RL, силовое, без защелки, SPST, 24В DC, 16А

Реле и Переключатели\Реле\Силовые РелеThe G2RL-1A-E-CV DC24 is a 1-pole Power PCB Relay with DC coil, G2RL series. SPST-NO contact configuration, high capacity classification. 16A, pinning 5mm, switching at 105°C. 10mm/10mm clearance and creepage distance. Offers high insulation with insulation distance above 8mm and impulse withstand voltage of 10kV between coil and contacts. Satisfies ambient operating temperature requirement of 85°C. Standard model conforms to VDE standards. Meets EN60335-1 requirements for household products. • Flux protection enclosure• Available in flux protection and fully sealed enclosure types• SPST-NO, SPDT, DPST-NO, DPDT contact configurations• UL, CSA and VDE standards approved• Non latching coil type• Low coil power of 400mW• CV version available with 16A contact current, pinning 5mm, switching at 105°C• Available in 8A, 12A and 16A switching current based on models• Selectable coil voltage of 5VDC, 12VDC, 24VDC, 48VDC
