APAN3105, Реле: электромагнитное, SPST-NO, Uобмотки: 5ВDC, 5A/250ВAC, 110мВт

• Contact configuration is SPST-NO, bifurcated• Nominal operating voltage range from 5VDC• Nominal operating power is 110mW• Nominal operating current is 22mA, coil resistance is 227ohm• Contact resistance is 30mohm• Contact material is AgNi type + Au• Nominal switching capacity is 5A 250VAC, 5A 30VDC• 3000V breakdown voltage and 6000V surge breakdown voltage• High density mounting of 5mm (W) x 20mm (L) x 12.5mm (H)• UL/C-UL and TUV certified
