ASP-208574-01, Board to Board & Mezzanine Connectors

Connectors\Board to Board & Mezzanine ConnectorsVITA 57.4 FMC+ - SEARAY™ ConnectorsSamtec VITA 57.4 FMC+ - SEARAY™ Connectors are high-speed and high-density arrays. These connectors come in High Serial Pin Connector (HSPC) or High Serial Pin Connector extension (HSPCe) variants. The HSPC has 560 pins arranged in a 14x40 array. Whereas, the HSPCe comes with an optional extension connector to boost pin-count by 80-positions, arranged in a 4x20 array. The VITA 57.4 FMC+ is the latest standard in the VITA FMC family. The specification increases the performance of the VITA 57.1 FMC standard by extending the total number of GigaBit transceivers to 32 and increasing the maximum data rate to 28Gbps. These FMC and FMC+ standards are essential for FPGA vendors to build baseboards and comprehensive development kits to enable designers to accelerate their application development.
