305-044-520-202, Standard Card Edge Connectors 44P SOLDER TAIL 3.56mm ROW SPACE

Connectors\Card Edge Connectors\Standard Card Edge Connectors305 Series 3.96mm Pitch Card Edge ConnectorsEDAC 305 Series 3.96mm Pitch Card Edge Connectors offer dual-row configuration and a variety of mounting options. These card edge connectors feature 3.56mm row spacing and accept a 1.57mm nominal thickness PCB. The EDAC 305 connectors accept between contact and in-contact polarizing keys. These card edge connectors offer 5A continuous current rating and 1800V ACrms withstand voltage at sea level between adjacent contacts. The 305 card edge connectors operate between -40°C to 105°C temperature range.
