69253-001LF, Conn Modular Jack F 4 POS 2.54mm Solder ST Thru-Hole 4 Terminal 1 Port Cat 3 Tube

Interconnect > Connectors > Telephone and TelecommThe 69253-001LF is a 1-port 4-position Cat3 vertical through mount unshielded Modular Jack Connector with copper alloy contact, high temp thermoplastic housing and diamond peg. It features a simple, flexible and low profile design for LAN application, in particular, the network interface card. It supports the transmission of 16Mbps signals targeted to phone, modem and POS terminal machines. • Vertical with 4 positions modular systems• Selective loading and one piece design assures coplanarity of solder tails and hold down• High temperature raw material• Suitable for high-speed Gigabit Ethernet applications• 20mR Contact resistance (maximum)• 250 Mating cycles durability• UL-94 V-0 Flammability rating• 1000V Signal to signal AC or DC voltage rating
