776488-1, Корпус разъема, Серия AMPSEAL, Гнездо, 4 вывод(-ов), 5.3 мм, Контактами AMPSEAL 16 (776488-1) — купить | ООО «Телеметрия»


776488-1, Корпус разъема, Серия AMPSEAL, Гнездо, 4 вывод(-ов), 5.3 мм, Контактами AMPSEAL 16

Оставить отзыв
В избранноеВ сравнение
Артикул: 776488-1
Кнопки, переключатели, разъемы, реле Разъемы Штыревые и гнезда TE Connectivity 776488-1, Корпус разъема, Серия AMPSEAL ...
TE Connectivity
Информация о производителе
ПроизводительTE Connectivity
БрендTE Connectivity
Основные
application:Wire to Wire
630
- +
Бонус: 12.6 !
Бонусная программа
Итого: 630
Купить
  • Обзор
  • Характеристики
  • Отзывы (0)
  • Реквизиты
Industrial & Commercial Transportation TE Connectivity's (TE) comprehensive line of Industrial & Commercial Transportation products includes an unparalleled portfolio of rugged electrical connector products and sensor technologies. TE"s environmentally sealed connectors are designed to withstand the harshest environmental conditions and to keep vehicles moving forward. TE's portfolio of heavy-duty sensors helps vehicles operate safer, cleaner, and smarter. Applications range from heavy-duty trucks to construction equipment, mining vehicles to fire trucks, as well as boats, motorcycles, and tractors.
Информация о производителе
ПроизводительTE Connectivity
БрендTE Connectivity
Основные
application:Wire to Wire
body materialPBT GF
color:Red
colourred
contact gender:Without Pin Contacts
contact type:Plug
current rating:13 A
Дата загрузки25.03.2024
description/function:AMPSEAL 16, Housing for Male Terminals
factory pack quantity: factory pack quantity:1
flammability rating:UL94HB
genderMale
gender:Receptacle(Female)
height22.45 mm
housing materialGlass Fibre Reinforced PBT
housing material:Polybutylene Terephthalate(PBT)
ingress protectionIP67
категорияКнопки, переключатели, разъемы, реле/Разъемы
length24.6 mm
lock mate feature:Integrated in Housing
manufacturer:TE Connectivity
material:Plastic
maximum operating temperature:+125 C
minimum operating temperature:-40 C
mounting angle:Straight
mounting featureWithout
mounting style:Cable Mount/Free Hanging
mounting typeClip Mount
number of contacts4
number of positions4
number of positions:4 Position
number of rows2
number of rows:2 Row
operating temperature (max)70 °C, (75 °C), (80 °C), (85 °C), (90 °C), (100 °C), (105 °C), (110 °C), (120 °C), (125 °C)
operating temperature range-40-125 °C, (-40-125 °C)
operating voltage250 VDC
партномер8174736328
pitch:5.3 mm
product:Housings
product category:Automotive Connectors
product type:Automotive Connectors
row spacing:4.5 mm
seriesAMPSEAL 16
series:Ampseal 16
subcategory:Automotive Connectors
termination style:Crimp
typeAutomotive connector housing
вес, г0.08
voltage rating:250 VDC
Время загрузки14:04:25
width47.55 mm
wire gauge max:14 AWG
wire gauge min:20 AWG
wire gauge range:14 AWG to 20 AWG
