702461001
Оставить отзыв
В избранноеВ сравнение
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Mates 70058 Series terminals typical stock number 670-6293 Gold plating depth 0.38 μm unless otherwise statedundefined
| Информация о производителе | |
| Производитель | Molex |
| Бренд | Molex |
| Основные | |
| applications | Automotive, General Purpose, Lighting, Medical, Telecommunications |
| application: | Wire-to-Board, Signal |
| automotive | No |
| body orientation | Straight |
| connector type | Header |
| contact finish - mating | Gold |
| contact finish thickness - mating | 15.0Вµin(0.38Вµm) |
| contact gender: | Pin(Male) |
| contact material | Phosphor Bronze |
| contact material: | Tin |
| contact plating | Gold |
| contact plating: | Gold |
| contact plating thickness | 0.381um |
| contact type | Male Pin |
| current rating | 2.5A |
| current rating: | 2.5 A |
| current rating (amps) | - |
| Дата загрузки | 25.03.2024 |
| eccn (us) | ear99 |
| factory pack quantity: factory pack quantity: | 1200 |
| fastening type | Push-Pull |
| features | Keying Slot |
| flammability rating: | UL 94 V-0 |
| gender | HDR |
| housing material: | Polyester |
| insulation color | Black |
| insulation height | 0.365"(9.27mm) |
| insulation material | Polybutylene Terephthalate(PBT), Glass Filled |
| insulation resistance (mohm) | 12000 |
| категория | Кнопки, переключатели, разъемы, реле/Разъемы |
| manufacturer | Molex |
| manufacturer: | Molex |
| material flammability rating | UL94 V-0 |
| mating post length: | 6.1 mm |
| maximum contact resistance (mohm) | 15 |
| maximum current rating (a) | 2.5/Contact |
| maximum operating temperature: | +120 C |
| maximum operating temperature (°c) | 120 |
| maximum voltage rating | 250VDC |
| minimum operating temperature: | -55 C |
| minimum operating temperature (°c) | -55 |
| mounting | Through Hole |
| mounting angle: | Straight |
| mounting style: | Through Hole |
| mounting type | Through Hole |
| number of contacts | 10 |
| number of positions | 10 |
| number of positions: | 10 Position |
| number of positions loaded | All |
| number of rows | 2 |
| number of rows: | 2 Row |
| operating temperature | - |
| packaging | Tray |
| packaging: | Tray |
| партномер | 8006067921 |
| part # aliases: | 702461001 |
| part status | active |
| pitch | 2.54mm |
| pitch: | 2.54 mm |
| polarization type | Center Slot |
| ppap | No |
| product: | Headers |
| product category: | Headers & Wire Housings |
| product type: | Headers & Wire Housings |
| row spacing: | 2.54 mm |
| row spacing (mm) | 2.54 |
| series | C-Grid 70246 |
| series: | 70246 |
| series number | 70246 |
| shrouded/unshrouded | Shrouded |
| style | Board to Cable/Wire |
| subcategory: | Headers & Wire Housings |
| terminal pitch (mm) | 2.54 |
| termination | Solder |
| termination method | Solder |
| termination post length: | 3.43 mm |
| termination style: | Solder Pin |
| tradename | C-Grid |
| tradename: | C-Grid |
| type | Shrouded Header(4 Sides) |
| type: | Shrouded |
| voltage rating | - |
| voltage rating: | 250 VDC |
