33012-3002, Automotive Connectors MX150 CRMP18-20AWG L Reel of 6000

Оставить отзыв
В избранноеВ сравнение
Артикул: 33012-3002
Кнопки, переключатели, разъемы, реле Разъемы Штыревые и гнезда Molex 33012-3002, Automotive Connectors MX150 ...
Информация о производителе
ПроизводительMolex
БрендMolex
Основные
application:Power
23
- +
Бонус: 0.46 !
Бонусная программа
Итого: 23
Купить
  • Обзор
  • Характеристики
  • Отзывы (0)
  • Реквизиты
Connectors\Automotive ConnectorsTransportation Solutions Molex Transportation Solutions help enable technology that transforms the future and improves people"s lives. The growth in trends such as connectivity, autonomous driving, in-vehicle experience, and electrification are introducing future-ready applications to everyday vehicles. Molex technology and expertise enable high-speed displays, reduced wiring complexity, and a safer, quieter, more enjoyable driving experience. Applications include sophisticated dashboard displays, fully integrated high-speed in-vehicle networks, enhanced safety devices, and high-performance engines and transmissions.
Информация о производителе
ПроизводительMolex
БрендMolex
Основные
application:Power
body orientationStraight
connector typeConnector Power
contact genderSKT
contact materialHighPerformanceAlloy
contact material:High Performance Alloy(HPA)
contact platingTin over Nickel
contact plating:Tin
contact typePower
contact type:Receptacle
current rating:22 A
current rating (max)22(A)
Дата загрузки24.09.2023
description/function:MX150 Female Terminal For Mat-Sealed Connectors
eccn (us)ear99
eu rohscompliant
factory pack quantity: factory pack quantity:6000
features:Left Reel Payoff, Small Polarization Rib
for use withMX150 Connector Housing
genderSKT
gender:Socket(Female)
housing materialNot Required
hts8536.69.80.00
категорияКнопки, переключатели, разъемы, реле/Разъемы
manufacturer:Molex
mating cycle (cycles)25
maximum current rating (a)22
maximum operating temperature+125°C
maximum voltage rating14VDC
maximum wire size awg18AWG
maximum wire size mm²0.8mm²
minimum operating temperature-40°C
minimum wire size awg20AWG
minimum wire size mm²0.6mm²
mountingCable Mount
mounting styleCable
mounting style:Cable Mount/Free Hanging
packagingTape and Reel
packaging:Reel
партномер8004870955
part statusactive
product:Terminals
product category:Automotive Connectors
product depth (mm)03.01.2023
product length (mm)20.45
product type:Automotive Connectors
product weight (g)0.434
seriesMX150
series:33012
series number33012
subcategory:Automotive Connectors
termination methodCrimp
termination styleCrimp
termination style:Crimp
tradenameMX150™
tradename:MX150
typeContact
вес, г0.39
voltage rating:14 V
Время загрузки15:39:37
wire gauge18-20(AWG)
wire gauge max:18 AWG
wire gauge min:20 AWG
wire gauge range:18 AWG to 20 AWG
wire size (awg)18-20
