The TE Connectivity's PCB connector housing provide a quality receptacle for connector when they are mounted to a printed circuit board.
Информация о производителе
Производитель
TE Connectivity
Бренд
TE Connectivity
Основные
application:
Wire-to-Board
body orientation
Straight
contact gender:
Socket(Female)
current rating:
2 A
Дата загрузки
04.04.2024
factory pack quantity: factory pack quantity:
250
flammability rating:
UL 94 V-0
gender
Female
housing color
Black
housing material:
Liquid Crystal Polymer(LCP)
insulation resistance:
1000 MOhms
категория
Кнопки, переключатели, разъемы, реле/Разъемы
количество положений
8вывод(-ов)
latching type:
Detent Latching
линейка продукции
AMPMODU
manufacturer:
TE Connectivity
maximum operating temperature:
+125 C
minimum operating temperature:
-40 C
mounting style:
Cable Mount/Free Hanging
number of contacts
8
number of positions:
8 Position
number of rows
2
number of rows:
2 Row
партномер
8006593339
pitch
2mm
pitch:
2 mm
product:
Wire Housings
product category:
Headers & Wire Housings
product type:
Headers & Wire Housings
row spacing:
2 mm
series
AMPMODU
шаг контактов
2мм
subcategory:
Headers & Wire Housings
termination style:
Crimp
тип электрического разъема
Гнездо
type:
Receptacle Housings
voltage rating:
125 V
Время загрузки
10:47:38
