Name: 180-044-103L001, Fiber Optic Connectors 44P MALE SOLDER CUP
Brand: Norcomp
SKU: 180-044-103L001

Кнопки, переключатели, разъемы, реле Разъемы D-SUB и корпуса для них Norcomp 180-044-103L001, Fiber Optic Connectors 44P ...

Подробное описание

2 310 ₽

– +

Бонус: 46.2 !

Бонусная программа

Итого: 2 310 ₽

Купить

Connectors\Fiber Optic ConnectorsSolder cup d-subs available in 5 industry sizes/positions High Density (15 pin, 26 pin, 44 pin, 62 pin, 78 pin).

Информация о производителе
Производитель	Norcomp
Бренд	Norcomp
Основные
body orientation	Straight
color	-
connector style	D-Sub, High Density
connector type	Plug, Male Pins
contact finish	Gold
contact finish thickness	Flash
contact form	-
contact material	Brass
contact plating	gold flash
contact type	SIGNAL
current rating	5.0A
current rating (amps)	5A
Дата загрузки	05.04.2024
dielectric material	Polybutylene Terephthalate(PBT)
factory pack quantity: factory pack quantity:	50
features	Grounding Indents, Shielded
gender	Male
housing material	Steel
категория	Кнопки, переключатели, разъемы, реле/Разъемы
manufacturer	NorComp Inc.
manufacturer:	NorComp
material flammability rating	UL94 V-0
maximum operating temperature	+100°C
minimum operating temperature	-50.0°C
mounting type	Panel Mount
number of contacts	44
number of positions	44
number of positions:	44 Position
number of rows	3
operating temperature	-50В°C ~ 100В°C
packaging	Tray
packaging:	Tray
партномер	8004615236
part status	active
pitch	2.29mm
product category:	Fiber Optic Connectors
product type:	Fiber Optic Connectors
series	180
subcategory:	Fiber Optic
termination	Solder Cup
termination method	Solder
вес, г	10.02.2024
voltage rating	500 V
Время загрузки	18:34:48
width	12.6mm
wire gauge	-
