1720505, Pluggable Terminal Blocks 6 Pos 7.62mm pitch Through Hole Header

Оставить отзыв
В избранноеВ сравнение
Артикул: 1720505
Кнопки, переключатели, разъемы, реле Разъемы Корпуса разъемов и аксессуры Phoenix Contact 1720505, Pluggable Terminal Blocks 6 Pos ...
Информация о производителе
ПроизводительPhoenix Contact
БрендPhoenix Contact
Основные
colorGreen
2 790
+
Бонус: 55.8 !
Бонусная программа
Итого: 2 790
Купить
  • Обзор
  • Характеристики
  • Отзывы (0)
  • Реквизиты
Connectors\Terminal Blocks\Pluggable Terminal BlocksPC5 Terminal Blocks with Click-n-LockPhoenix Contact's COMBICON Power PC5 Terminal Blocks with Click-n-Lock provide an audible click that confirms the plug and header were properly mated and assures against accidental disconnect. The Click-n-Lock PC5 Terminal Blocks offer wire-to-wire and wire-to-board possibilities for a wide range of applications including power electronics, frequency converters, power supply units, electric vehicles, and engine connections.
Информация о производителе
ПроизводительPhoenix Contact
БрендPhoenix Contact
Основные
colorGreen
color:Green
contact material-
contact mating finishTin
contact plating:Tin
contact tail length0.197"(5.00mm)
current - iec41A
current rating:41 A
current - ul41A
Дата загрузки10.04.2024
dielectric materialPolyamide(PA), Nylon
factory pack quantity: factory pack quantity:50
featuresLatch Lock
header orientation90В°, Right Angle
ingress protection-
insulation height0.563"(14.30mm)
категорияКнопки, переключатели, разъемы, реле/Разъемы
manufacturerPhoenix Contact
manufacturer:Phoenix Contact
material flammability ratingUL94 V-0
mounting style:Through Hole
mounting typeThrough Hole
number of levels1
number of positions6
number of positions:6 Position
operating temperature-
packagingBulk
партномер8004707113
part # aliases:PC_5/_6-G-7.62 PC56G762
part statusactive
pitch0.300"(7.62mm)
pitch:7.62 mm
plug wire entry-
positions per level6
product:Headers
product category:Pluggable Terminal Blocks
product type:Pluggable Terminal Blocks
screw size-
seriesCOMBICON PC
series:PC
subcategory:Terminal Blocks
termination styleSolder
termination style:Solder Pin
torque - screw-
tradename:COMBICON Power
typeHeader, Male Pins, Shrouded(4 Side)
вес, г11.55
voltage - iec1kV
voltage rating:630 V
voltage - ul300V
Время загрузки13:10:06
wire gauge or range - awg-
wire gauge or range - mmві-
wire strip length-
