Temperature Sensor Thermo String TypeBasics of NTC
power rating
200mW
packaging
Tape and Reel
eu rohs
Compliant
maximum operating temperature (°c)
125
mounting
Surface Mount
part status
NRND
base product number
NCP21XV ->
eccn (us)
EAR99
minimum operating temperature (°c)
-40
hts
8533.40.80.70
Вес и габариты
tolerance
В±5%
construction
Solder Pad
number of terminals
2
product length (mm)
2
product depth (mm)
1.25
product height (mm)
0.85
application
Temperature Sensor|Temperature Compensation
power - max
200mW
resistance tolerance
В±5%
b value tolerance
В±3%
b25/100
3944K
resistance in ohms @ 25в°c
10k
b25/50
3900K
b25/85
3934K
b parameter
3900K
maximum power rating (w)
200m
percentage of resistance tolerance @ 25c (%)
±5
percentage of resistance tolerance range @ 25c (%)
±5 to ±10
resistance @ 25c (ohm)
10000
resistance range @ 25c (ohm)
6000 to 25000
sensitivity index (k)
3934
sensitivity index range (k)
3850 to 4100
