Дата загрузки | 18.02.2024 |
Вес и габариты | |
вес, г | 0.2 |
Информация о производителе | |
Производитель | STMicroelectronics |
Бренд | STMicroelectronics |
Основные | |
automotive | No |
base product number | ULN2002 -> |
collector- emitter voltage vceo max: | 50 V |
configuration | Array 7 |
configuration: | Array 7 |
current - collector cutoff (max) | 50ВµA |
current - collector (ic) (max) | 500mA |
dc collector/base gain hfe min: | 1000 at 350 mA at 2 V |
dc current gain (hfe) (min) @ ic, vce | 1000 @ 350mA, 2V |
eccn | EAR99 |
eccn (us) | EAR99 |
eu rohs | Compliant |
factory pack quantity: factory pack quantity: | 2500 |
htsus | 8541.29.0095 |
категория | Электронные компоненты/Транзисторы |
lead shape | Gull-wing |
manufacturer: | STMicroelectronics |
maximum base current (a) | 0.025 |
maximum collector emitter saturation voltage | 1.6 V |
maximum collector-emitter saturation voltage (v) | 1.1@250uA@100mA|1.3@350uA@200mA|1.6@500uA@350mA |
maximum collector emitter voltage | 50 V |
maximum collector-emitter voltage (v) | 50 |
maximum continuous collector current | 500 mA |
maximum continuous dc collector current (a) | 0.5 |
maximum dc collector current: | 500 mA |
maximum emitter base voltage (v) | 30 |
maximum operating temperature | +85 °C |
maximum operating temperature: | +85 C |
maximum operating temperature (°c) | 85 |
minimum dc current gain | 1000 |
minimum operating temperature | -20 °C |
minimum operating temperature: | -20 C |
minimum operating temperature (°c) | -40 |
moisture sensitivity level (msl) | 1 (Unlimited) |
mounting | Surface Mount |
mounting style: | SMD/SMT |
mounting type | Surface Mount |
number of elements per chip | 7 |
operating junction temperature (°c) | 150 |
operating temperature | -40В°C ~ 85В°C (TA) |
other related documents | http://www.st.com/web/catalog/sense_power/FM1968/C |
package | Tape & Reel (TR)Cut Tape (CT)Digi-ReelВ® |
package / case | 16-SOIC (0.154"", 3.90mm Width) |
package / case: | SOIC-16 |
package type | SOIC |
packaging | Tape and Reel |
партномер | 8004831898 |
part status | Active |
pcb changed | 16 |
pin count | 16 |
ppap | No |
product category: | Darlington Transistors |
product type: | Darlington Transistors |
reach status | REACH Unaffected |
rohs status | ROHS3 Compliant |
series: | ULN2002 |
standard package name | SO |
subcategory: | Transistors |
supplier device package | 16-SO |
supplier package | SO N |
supplier temperature grade | Industrial |
transistor configuration | Common Emitter |
transistor polarity: | NPN |
transistor type | 7 NPN Darlington |
type | NPN |
vce saturation (max) @ ib, ic | 1.6V @ 500ВµA, 350mA |
voltage - collector emitter breakdown (max) | 50V |
Время загрузки | 13:54:01 |
width | 4mm |
