Bipolar Junction Transistors (BJT) broad range provides complete solutions for various circuit application needs.
Дата загрузки | 21.02.2024 |
Вес и габариты | |
вес, г | 0.557 |
Информация о производителе | |
Производитель | ON Semiconductor*** |
Бренд | ON Semiconductor*** |
Основные | |
category | Bipolar Power |
collector- base voltage vcbo: | 1.2 kV |
collector-emitter saturation voltage: | 400 mV |
collector- emitter voltage vceo max: | 600 V |
configuration | Single |
configuration: | Single |
continuous collector current: | 2 A |
dc collector/base gain hfe min: | 14 |
emitter- base voltage vebo: | 12 V |
factory pack quantity: factory pack quantity: | 2500 |
frequency | 11(MHz) |
gain bandwidth product ft: | 11 MHz |
категория | Электронные компоненты/Транзисторы |
manufacturer: | onsemi |
maximum collector base voltage | 1200 V |
maximum collector emitter voltage | 600 V |
maximum dc collector current | 2 A |
maximum dc collector current: | 2 A |
maximum emitter base voltage | 12 V |
maximum operating frequency | 1 MHz |
maximum operating temperature | +150 °C |
maximum operating temperature: | +150 C |
maximum power dissipation | 50 W |
minimum dc current gain | 12 |
mounting | Surface Mount |
mounting style: | SMD/SMT |
mounting type | Surface Mount |
number of elements | 1 |
number of elements per chip | 1 |
operating temperature classification | Military |
operating temp range | -65C to 150C |
output power | Not Required(W) |
package / case: | DPAK-3 |
package type | DPAK(TO-252) |
packaging | Tape and Reel |
партномер | 8008460776 |
pd - power dissipation: | 87.83 W |
pin count | 3 |
power dissipation | 50(W) |
product category: | Bipolar Transistors-BJT |
product type: | BJTs-Bipolar Transistors |
rad hardened | No |
series: | KSC5502D |
subcategory: | Transistors |
technology: | Si |
transistor configuration | Single |
transistor polarity | NPN |
transistor polarity: | NPN |
transistor type | NPN |
Время загрузки | 0:56:04 |
