A broad range of NPN and PNP Bipolar Transistors from STMicroelectronics including General Purpose, Darlington, Power and High-Voltage devices in both SMT and Through-hole packages.
Дата загрузки
18.02.2024
Информация о производителе
Производитель
STMicroelectronics
Бренд
STMicroelectronics
Основные
collector- base voltage vcbo
80 V
collector- emitter voltage vceo max
80 V
configuration
Single
continuous collector current
8 A
dc collector/base gain hfe min
750
emitter- base voltage vebo
5 V
factory pack quantity
1000
height
9.15 mm
категория
Электронные компоненты/Транзисторы
length
10.4 mm
manufacturer
STMicroelectronics
maximum base emitter saturation voltage
2.5 V
maximum collector base voltage
80 V
maximum collector cut-off current
200 uA
maximum collector emitter saturation voltage
2 V
maximum collector emitter voltage
80 V
maximum continuous collector current
8 A
maximum dc collector current
8 A
maximum emitter base voltage
5 V
maximum operating temperature
+150 C
minimum dc current gain
750
minimum operating temperature
-65 °C
mounting style
Through Hole
mounting type
Through Hole
number of elements per chip
1
package / case
TO-220-3
package type
TO-220
packaging
Tube
партномер
8005957170
pd - power dissipation
60 W
pin count
3
product category
Darlington Transistors
rohs
Details
series
Darlingtons
transistor configuration
Single
transistor polarity
NPN
transistor type
NPN
Время загрузки
13:57:18
width
4.6 mm
