LTO030F2R200JTE3

ЭлектроэлементRES, 2R2, 5%, 30W, TO-220, THICK FILM; Resistance:2.2ohm; Product Range:LTO 30 Series; Power Rating:30W; Resistance Tolerance:± 5%; Resistor Case Style:TO-220; Voltage Rating:250V; Resistor Element Material:Thick Film; Temperature Coefficient:± 150ppm/°C; Automotive Qualification Standard:-; External Depth:3.2mm; External Length / Height:16.2mm; External Width:10.4mm; No. of Pins:2Pins; Operating Temperature Max:150°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +150°C; Resistor Mounting:Through Hole; Temperature Coeff. +:150ppm/°C; Temperature Coeff. -:150ppm/°C; Tolerance +:5%; Tolerance -:5%; Voltage Rating V DC:250V
