TSZ121IYLT, TSZ121IYLT, Operational Amplifier, Op Amp, RRIO, 400kHz 1 kHz, 1.8 5.5 V, 5-Pin SOT-23
Оставить отзыв
В избранноеВ сравнение
Артикул: TSZ121IYLT
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Semiconductors\Amplifiers & Comparators\Op AmpsThe TSZ12x series of high precision operational amplifiers offer very low input offset voltages with virtually zero drift.
| Информация о производителе | |
| Производитель | STMicroelectronics |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 0:35:54 |
| Бренд | STMicroelectronics |
| Вес и габариты | |
| amplifier type | Operational Amplifier |
| amplifier type: | Zero Drift Amplifier |
| automotive | Yes |
| automotive standard | AEC-Q100 |
| cmrr - common mode rejection ratio | 136 dB |
| cmrr - common mode rejection ratio: | 136 dB |
| диапазон напряжения питания | 1.8В до 5.5В |
| eccn (us) | ear99 |
| en - input voltage noise density: | 50 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity | 3000 |
| factory pack quantity: factory pack quantity: | 3000 |
| gbp - gain bandwidth product | 400 kHz |
| gbp - gain bandwidth product: | 400 kHz |
| ib - input bias current | 200 pA |
| ib - input bias current: | 200 pA |
| input offset current | 600pA |
| input voltage range | 1.8 → 5.5 V |
| ios - input offset current | 400 pA |
| ios - input offset current: | 400 pA |
| категория | Электронные компоненты/Микросхемы |
| количество усилителей | 1 Усилитель |
| количество выводов | 5вывод(-ов) |
| lead shape | Gull-wing |
| максимальная рабочая температура | 125°C |
| manufacturer | STMicroelectronics |
| manufacturer: | STMicroelectronics |
| manufacturer type | Micropower Amplifier |
| maximum input bias current (ua) | 0.0002@5V |
| maximum input offset current (ua) | 0.0004@5V |
| maximum input offset voltage (mv) | 0.005@5V |
| maximum input voltage | 5.5 V |
| maximum operating frequency | 1 kHz |
| maximum operating temperature | +125 °C |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum single supply voltage (v) | 05.05.2024 |
| maximum supply current (ma) | 0.04@5V |
| минимальная рабочая температура | -40°C |
| minimum cmrr (db) | 115 |
| minimum cmrr range (db) | >=115 |
| minimum input voltage | 1.8 V |
| minimum operating temperature | -40 °C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum single supply voltage (v) | 01.08.2024 |
| mounting | surface mount |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels | 1 Channel |
| number of channels: | 1 Channel |
| number of channels per chip | 1 |
| offset voltage | 8µV |
| operating supply current | 40 uA |
| operating supply current: | 40 uA |
| output current | 17(Sink)mA, 18(Source)mA |
| output current per channel | 17 mA |
| output current per channel: | 17 mA |
| output type | Rail to Rail |
| package / case | SOT23-5 |
| package / case: | SOT-23-5 |
| package type | SOT-23 |
| packaging | Tape and Reel |
| партномер | 8014516026 |
| part status | active |
| pcb changed | 5 |
| pin count | 5 |
| полоса пропускания | 400кГц |
| power supply type | Single |
| ppap | Yes |
| process technology | CMOS |
| product | Precision Amplifiers |
| product: | Precision Amplifiers |
| product category | Precision Amplifiers |
| product category: | Precision Amplifiers |
| product type: | Precision Amplifiers |
| qualification: | AEC-Q100 |
| rail to rail | Rail to Rail Input/Output |
| rohs | Details |
| series | TSZ121 |
| series: | TSZ121 |
| shutdown: | No Shutdown |
| shut down support | No |
| скорость нарастания | 0.19В/мкс |
| sr - slew rate | 0.19 V/us |
| sr - slew rate: | 190 mV/us |
| standard package name | SOT |
| стандарты автомобильной промышленности | AEC-Q100 |
| стиль корпуса усилителя | SOT-23 |
| subcategory: | Amplifier ICs |
| supplier package | SOT-23 |
| supplier temperature grade | Automotive |
| supply voltage - max | 5.5 V |
| supply voltage - max: | 5.5 V |
| supply voltage - min | 1.8 V |
| supply voltage - min: | 1.8 V |
| type | Micropower Amplifier |
| typical gain bandwidth product | 400kHz |
| typical gain bandwidth product (mhz) | 0.4 |
| typical input noise voltage density (nv/rthz) | 37@5V |
| typical input voltage noise density | 60nV/√Hz |
| typical output current (ma) | 18@5V |
| typical settling time (ns) | 10000 |
| typical single supply voltage | 1.8 → 5.5 V |
| typical single supply voltage (v) | 5|3 |
| typical slew rate | 0.19V/µs |
| typical slew rate (v/us) | 0.19@5V |
| typical voltage gain | 135 dB |
| typical voltage gain (db) | 135 |
| уровень чувствительности к влажности (msl) | MSL 1-Безлимитный |
| вес, г | 0.5 |
| voltage gain db | 135 dB |
| voltage gain db: | 135 dB |
| vos - input offset voltage | 5 uV |
| vos - input offset voltage: | 5 uV |
| width | 1.75mm |
