| Информация о производителе | |
| Производитель | STMicroelectronics |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 22:21:42 |
| Бренд | STMicroelectronics |
| Вес и габариты | |
| amplifier type | General Purpose |
| amplifier type: | Low Noise Amplifier |
| base product number | TS974 -> |
| cmrr - common mode rejection ratio | 60 dB |
| cmrr - common mode rejection ratio: | 85 dB |
| current - input bias | 200nA |
| current - output / channel | 100mA |
| current - supply | 2mA (x4 Channels) |
| dual supply voltage | +/-3 V |
| dual supply voltage: | +/-3 V |
| eccn | EAR99 |
| en - input voltage noise density | 4 nV/sqrt Hz |
| en - input voltage noise density: | 4 nV/sqrt Hz |
| factory pack quantity | 2500 |
| factory pack quantity: factory pack quantity: | 2500 |
| gain bandwidth product | 12MHz |
| gbp - gain bandwidth product | 12 MHz |
| gbp - gain bandwidth product: | 12 MHz |
| height | 1.65 mm(Max) |
| htsus | 8542.33.0001 |
| ib - input bias current | 750 nA |
| ib - input bias current: | 750 nA |
| input offset current | 150nA |
| input voltage range | 2.7 → 10 V |
| категория | Электронные компоненты/Микросхемы |
| length | 8.75 mm(Max) |
| manufacturer | STMicroelectronics |
| manufacturer: | STMicroelectronics |
| maximum dual supply voltage | +/-5 V |
| maximum dual supply voltage: | +/-5 V |
| maximum input voltage | 10 V |
| maximum operating temperature | +125 °C |
| maximum operating temperature: | +125 C |
| minimum dual supply voltage | +/-1.35 V |
| minimum dual supply voltage: | +/-1.35 V |
| minimum input voltage | 2.7 V |
| minimum operating temperature | -40 °C |
| minimum operating temperature: | -40 C |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels | 4 Channel |
| number of channels: | 4 Channel |
| number of channels per chip | 4 |
| number of circuits | 4 |
| offset voltage | 7mV |
| operating supply current | 11.2 mA |
| operating supply current: | 2 mA |
| operating supply voltage | 2.7 V to 10 V, +/-1.35 V to+/-5 V |
| operating supply voltage: | 2.7 V to 10 V, +/-1.35 V to+/-5 V |
| operating temperature | -40В°C ~ 125В°C |
| output current | 100 mA |
| output current per channel | 100 mA |
| output current per channel: | 100 mA |
| output type | Rail-to-Rail |
| package | Tape & Reel (TR)Cut Tape (CT)Digi-ReelВ® |
| package / case | 14-SOIC (0.154"", 3.90mm Width) |
| package / case: | SOIC-14 |
| package type | SOIC |
| packaging | Reel |
| партномер | 8004831598 |
| pin count | 14 |
| power supply type | Single |
| product | Operational Amplifiers |
| product: | Operational Amplifiers |
| product category | Operational Amplifiers-Op Amps |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| psrr - power supply rejection ratio | 60 dB |
| psrr - power supply rejection ratio: | 60 dB |
| rail to rail | Rail to Rail Output |
| reach status | REACH Unaffected |
| rohs | Details |
| rohs status | ROHS3 Compliant |
| series | Automotive, AEC-Q100 -> |
| series: | TS974 |
| shutdown | No Shutdown |
| shutdown: | No Shutdown |
| slew rate | 4V/Вµs |
| sr - slew rate | 4 V/us |
| sr - slew rate: | 4 V/us |
| subcategory: | Amplifier ICs |
| supplier device package | 14-SO |
| supply type | Single, Dual |
| supply type: | Single, Dual |
| supply voltage - max | 10 V |
| supply voltage - max: | 10 V, +/-5 V |
| supply voltage - min | 2.7 V |
| supply voltage - min: | 2.7 V, +/-1.35 V |
| typical dual supply voltage | ±3V |
| typical gain bandwidth product | 12MHz |
| typical input voltage noise density | 4nV/√Hz |
| typical single supply voltage | 2.7 → 10 V |
| typical slew rate | 4V/µs |
| typical voltage gain | 80 dB |
| вес, г | 0.26 |
| voltage gain db | 80 dB |
| voltage gain db: | 80 dB |
| voltage - input offset | 1mV |
| voltage - supply, single/dual (в±) | 2.7V ~ 10V, В±1.35V ~ 5V |
| vos - input offset voltage | 5 mV |
| vos - input offset voltage: | 5 mV |
| width | 4mm |
