TLV2462ID, Operational Amplifiers - Op Amps Dual Low Power
Оставить отзыв
В избранноеВ сравнение
Артикул: TLV2462ID
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Semiconductors\Amplifier ICs\Operational Amplifiers - Op AmpsУсилитель общего назначения, 2 схемы, Rail-to-Rail 8-SOIC
| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 22:21:19 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| amplifier type | General Purpose |
| amplifier type: | Low Power Amplifier |
| automotive | No |
| base product number | TLV2462 -> |
| cmrr - common mode rejection ratio: | 85 dB |
| current - input bias | 1.3nA |
| current - output / channel | 80mA |
| current - supply | 550ВµA (x2 Channels) |
| dual supply voltage: | +/-3 V |
| eccn | EAR99 |
| en - input voltage noise density: | 11 nV/sqrt Hz |
| factory pack quantity: factory pack quantity: | 75 |
| gain bandwidth product | 6.4MHz |
| gbp - gain bandwidth product: | 6.4 MHz |
| htsus | 8542.33.0001 |
| ib - input bias current: | 14 nA |
| input type: | Rail-to-Rail |
| in - input noise current density: | 0.13 pA/sqrt Hz |
| категория | Электронные компоненты/Микросхемы |
| manufacturer: | Texas Instruments |
| maximum dual supply voltage: | +/-3 V |
| maximum input bias current - (ua) | 0.014@5V |
| maximum input offset current - (ua) | 0.007@5V |
| maximum input offset voltage - (mv) | 2@5V |
| maximum operating temperature | +125 °C |
| maximum operating temperature: | +125 C |
| maximum power dissipation - (mw) | 710 |
| military | No |
| minimum dual supply voltage: | +/-1.35 V |
| minimum operating temperature | -40 °C |
| minimum operating temperature: | -40 C |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels: | 2 Channel |
| number of channels per chip | 2 |
| number of circuits | 2 |
| operating supply current: | 550 uA |
| operating supply voltage: | 2.7 V to 6 V, +/-1.35 V to+/-3 V |
| operating temperature | -40В°C ~ 125В°C (TA) |
| operating temperature - (??c) | -40~125 |
| output current per channel: | 80 mA |
| output type | Rail-to-Rail |
| output type: | Rail-to-Rail |
| package | Tube |
| package / case | 8-SOIC (0.154"", 3.90mm Width) |
| package / case: | SOIC-8 |
| package type | SOIC |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8005014623 |
| pd - power dissipation: | 710 mW |
| pin count | 8 |
| power supply type | Dual, Single |
| product: | Operational Amplifiers |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| rail to rail | Rail to Rail Input/Output |
| reach status | REACH Unaffected |
| rohs status | ROHS3 Compliant |
| series | Automotive, AEC-Q100 -> |
| series: | TLV2462 |
| shutdown: | No Shutdown |
| shut down support | No |
| slew rate | 1.6V/Вµs |
| sr - slew rate: | 1.6 V/us |
| standard package name | SOP |
| subcategory: | Amplifier ICs |
| supplier device package | 8-SOIC |
| supplier package | SOIC |
| supply type: | Single, Dual |
| supply voltage - max: | 6 V |
| supply voltage - min: | 2.7 V |
| typical gain bandwidth product | 6.4MHz |
| typical gain bandwidth product - (mhz) | 06.04.2024 |
| typical input voltage noise density | 14nV/√Hz |
| typical single supply voltage | 3 V, 5 V |
| typical slew rate | 1.6V/µs |
| typical slew rate - (v/us) | 1.6@5V |
| typical voltage gain | 109 dB |
| вес, г | 0.08 |
| voltage gain db: | 109 dB |
| voltage - input offset | 500ВµV |
| voltage - supply, single/dual (в±) | 2.7V ~ 6V, В±1.35V ~ 3V |
| vos - input offset voltage: | 2 mV |
| width | 3.91mm |
