| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 0:35:00 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| amplifier type | General Purpose Amplifier |
| amplifier type: | JFET Operational Amplifiers |
| cmrr - common mode rejection ratio | 70 dB |
| cmrr - common mode rejection ratio: | 86 dB |
| dual supply voltage | +/-5 V, +/-9 V, +/-12 V, +/-15 V |
| dual supply voltage: | +/-5 V, +/-9 V, +/-12 V, +/-15 V |
| en - input voltage noise density | 18 nV/sqrt Hz |
| en - input voltage noise density: | 18 nV/sqrt Hz |
| factory pack quantity | 2500 |
| factory pack quantity: factory pack quantity: | 750 |
| gbp - gain bandwidth product | 3 MHz |
| gbp - gain bandwidth product: | 3 MHz |
| height | 1.58 mm |
| ib - input bias current | 400 pA |
| ib - input bias current: | 400 pA |
| input type: | Rail-to-Rail |
| in - input noise current density | 0.01 pA/sqrt Hz |
| in - input noise current density: | 0.01 pA/sqrt Hz |
| категория | Электронные компоненты/Микросхемы |
| length | 4.9 mm |
| manufacturer | Texas Instruments |
| manufacturer: | Texas Instruments |
| maximum dual supply voltage | +/-18 V |
| maximum dual supply voltage: | 18 V |
| maximum operating temperature | +70 C |
| maximum operating temperature: | +85 C |
| minimum dual supply voltage | +/-3.5 V |
| minimum dual supply voltage: | 3.5 V |
| minimum operating temperature | 0 C |
| minimum operating temperature: | -40 C |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| number of channels | 1 Channel |
| number of channels: | 1 Channel |
| operating supply current | 2.8 mA |
| operating supply current: | 1.4 mA |
| operating supply voltage | 7 V to 36 V, +/-3.5 V to+/-18 V |
| operating supply voltage: | 15 V |
| output current per channel: | 10 mA |
| package / case | SOIC-8 |
| package / case: | SOIC-8 |
| packaging | Reel |
| packaging: | Tube |
| партномер | 8002646814 |
| pd - power dissipation | 680 mW |
| pd - power dissipation: | 680 mW |
| product | Operational Amplifiers |
| product: | Operational Amplifiers |
| product category | Operational Amplifiers-Op Amps |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| rohs | Details |
| series | TL081 |
| series: | TL081 |
| shutdown | No Shutdown |
| shutdown: | No Shutdown |
| sr - slew rate | 13 V/us |
| sr - slew rate: | 13 V/us |
| subcategory: | Amplifier ICs |
| supply type | Single, Dual |
| supply type: | Single, Dual |
| supply voltage - max | 36 V |
| supply voltage - max: | 30 V |
| supply voltage - min | 7 V |
| supply voltage - min: | 7 V |
| technology | BiFET |
| technology: | BiFET |
| unit weight | 0.002561 oz |
| vcm - common mode voltage | Negative Rail+4 V to Positive Rail-4 V |
| vcm - common mode voltage: | Negative Rail+4 V to Positive Rail-4 V |
| вес, г | 0.07 |
| voltage gain db | 106.02 dB |
| voltage gain db: | 106.02 dB |
| vos - input offset voltage | 15 mV |
| vos - input offset voltage: | 15 mV |
| width | 3.91 mm |
