THS3202DGN, High Speed Operational Amplifiers 2GHz Current Feedback Amplifier
Оставить отзыв
В избранноеВ сравнение
Артикул: THS3202DGN
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Semiconductors\Amplifier ICs\High Speed Operational AmplifiersЦепь 2 усилителя обратной связи по току 8-MSOP-PowerPad
| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 22:16:26 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| amplifier type | Current Feedback |
| automotive | No |
| base product number | THS3202 -> |
| cmrr - common mode rejection ratio | 60 dB |
| cmrr - common mode rejection ratio: | 71 dB |
| current - input bias | 13ВµA |
| current - output / channel | 120mA |
| current - supply | 14mA (x2 Channels) |
| development kit | THS3202EVM |
| development kit: | THS3202EVM |
| eccn | EAR99 |
| eccn (us) | ear99 |
| en - input voltage noise density | 1.65 nV/sqrt Hz |
| en - input voltage noise density: | 1.65 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity | 80 |
| factory pack quantity: factory pack quantity: | 80 |
| gbp - gain bandwidth product | 2 GHz |
| gbp - gain bandwidth product: | 2 GHz |
| height | 1.02 mm |
| htsus | 8542.33.0001 |
| ib - input bias current | 35 uA |
| ib - input bias current: | 85 uA |
| input offset voltage drift (uv/°c) | ±13(Typ) |
| категория | Электронные компоненты/Микросхемы |
| lead shape | Gull-wing |
| length | 3 mm |
| manufacturer | Texas Instruments |
| manufacturer: | Texas Instruments |
| manufacturer type | High Speed Amplifier |
| maximum dual supply voltage (v) | ±7.5 |
| maximum input bias current (ua) | 35@±5V |
| maximum input offset voltage (mv) | 3@±5V |
| maximum operating temperature | +85 C |
| maximum operating temperature: | +85 C |
| maximum operating temperature (°c) | 85 |
| maximum power dissipation (mw) | 1710 |
| maximum quiescent current (ma) | 33.6@±5V |
| maximum single supply voltage (v) | 15 |
| minimum cmrr (db) | 60 |
| minimum cmrr range (db) | 60 to 65 |
| minimum dual supply voltage (v) | ±3.3 |
| minimum operating temperature | -40 C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 63 |
| minimum single supply voltage (v) | 06.06.2024 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting | surface mount |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels | 2 Channel |
| number of channels: | 2 Channel |
| number of channels per chip | 1 |
| number of circuits | 2 |
| operating supply current | 36 mA |
| operating supply current: | 14 mA |
| operating supply voltage | 15 V |
| operating supply voltage: | 15 V |
| operating temperature | -40В°C ~ 85В°C |
| output current per channel: | 115 mA |
| package | Tube |
| package / case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) Exposed Pa |
| package / case: | MSOP-8 |
| package type | MSOP |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8005011946 |
| part status | NRND |
| pcb changed | 8 |
| pd - power dissipation | 1710 mW |
| pd - power dissipation: | 1710 mW |
| pin count | 8 |
| power supply type | Single |
| ppap | No |
| process technology | BiCOM-II |
| product | Operational Amplifiers |
| product: | Operational Amplifiers |
| product category | High Speed Operational Amplifiers |
| product category: | High Speed Operational Amplifiers |
| product type: | Op Amps-High Speed Operational Amplifiers |
| psrr - power supply rejection ratio | 63 dB |
| psrr - power supply rejection ratio: | 63 dB |
| reach status | REACH Unaffected |
| rohs | Details |
| rohs status | ROHS3 Compliant |
| series | THS3202 |
| series: | THS3202 |
| shut down support | No |
| slew rate | 9000V/Вµs |
| sr - slew rate | 5100 V/us |
| sr - slew rate: | 9 kV/us |
| standard package name | SOP |
| subcategory: | Amplifier ICs |
| supplier device package | 8-MSOP-PowerPad |
| supplier package | HVSSOP EP |
| supply voltage - max | 15 V |
| supply voltage - max: | 15 V |
| supply voltage - min | 6.6 V |
| supply voltage - min: | 6.6 V |
| type | High Speed Amplifier |
| typical dual supply voltage (v) | ±5 |
| typical gain bandwidth product | 2MHz |
| typical gain bandwidth product (mhz) | 2000 |
| typical input bias current (ua) | 14@±5V |
| typical input noise voltage density (nv/rthz) | 1.65@±5V |
| typical inverting input current noise density (pa/rthz) | 20@±5V |
| typical noninverting input current noise density (pa/rthz) | 13.4@±5V |
| typical output current (ma) | 115@±5V |
| typical settling time (ns) | 118 |
| typical slew rate (v/us) | 5100@±5V |
| unit weight | 0.000861 oz |
| вес, г | 0.02 |
| voltage - input offset | 700ВµV |
| voltage - supply, single/dual (в±) | 6.6V ~ 15V, В±3.3V ~ 7.5V |
| vos - input offset voltage | 4 mV |
| vos - input offset voltage: | 700 uV |
| width | 3 mm |
| -3db bandwidth | 2GHz |
