Микросхемы\Усилители – Инструментальные, Операционные, БуферныеМикросхема, операционный усилитель, 1-18МГц, 2,5-5,5В, Ch: 1, SO8

Подробное описание

Основные
mounting type	Surface Mount
package type	SOIC N
minimum operating temperature	-40 °C
width	3.9mm

410 ₽

– +

Бонус: 8.2 !

Бонусная программа

Итого: 410 ₽

Купить

Основные
mounting type	Surface Mount
package type	SOIC N
minimum operating temperature	-40 °C
width	3.9mm
pin count	8
maximum operating temperature	+125 °C
packaging	Rail/Tube
mounting	surface mount
power supply type	Single
output type	Rail to Rail
number of channels	1
Вес и габариты
typical single supply voltage	3 V, 5 V
number of channels per chip	1
rail to rail	Rail to Rail Input/Output
input resistance	10000000(MOhm)
operating temp range	-40C to 125C
operating temperature classification	Automotive
rad hardened	No
dual supply voltage (max)	Not Required(V)
dual supply voltage (min)	Not Required(V)
dual supply voltage (typ)	Not Required(V)
power supply requirement	Single
single supply voltage (max)	5.5(V)
single supply voltage (min)	2.5(V)
single supply voltage (typ)	3/5(V)
number of elements	1
voltage gain db	30.1(dB)
maximum input resistance	10000000MΩ
input offset voltage	4(mV)
power supply rejection ratio	70(dB)
input bias current	0.001(nA)
maximum input offset voltage	4mV
