| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 4:00:09 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| amplifier type | Audio |
| amplifier type: | Audio |
| application | Speaker |
| automotive | No |
| base product number | OPA1671 -> |
| cmrr - common mode rejection ratio: | 102 dB |
| current - input bias | 10pA |
| current - output / channel | 66mA |
| current - supply | 940ВµA |
| eccn | EAR99 |
| eccn (us) | ear99 |
| en - input voltage noise density: | 4 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 250 |
| features: | Small Size |
| function | Speaker |
| gain bandwidth product | 13MHz |
| gbp - gain bandwidth product: | 13 MHz |
| htsus | 8542.33.0001 |
| ib - input bias current: | 10 pA |
| input type: | Rail-to-Rail |
| in - input noise current density: | 4.7 fA/sqrt Hz |
| ios - input offset current: | 10 pA |
| категория | Электронные компоненты/Микросхемы |
| manufacturer: | Texas Instruments |
| manufacturer product page | http://www.ti.com/general/docs/suppproductinfo.tsp |
| maximum dual supply voltage: | +/-2.75 V |
| maximum dual supply voltage (v) | ±2.75 |
| maximum input bias current (ua) | 0.00001(Typ)@5.5V |
| maximum input offset voltage (mv) | 1.25@5.5V |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum quiescent current (ma) | 1.3@5.5V |
| maximum single supply voltage (v) | 05.05.2024 |
| minimum dual supply voltage: | +/-850 mV |
| minimum dual supply voltage (v) | ±0.85 |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum single supply voltage (v) | 01.07.2024 |
| moisture sensitive: | Yes |
| moisture sensitivity level (msl) | 2 (1 Year) |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels: | 1 Channel |
| number of channels per chip | 1 |
| number of circuits | 1 |
| operating supply current: | 940 uA |
| operating temperature | -40В°C ~ 125В°C |
| output current per channel: | 66 mA |
| output signal type | Single |
| output type | Rail-to-Rail |
| output type: | Rail-to-Rail |
| package | Tape & Reel (TR)Cut Tape (CT)Digi-ReelВ® |
| package / case | 5-TSSOP, SC-70-5, SOT-353 |
| package / case: | SC-70-5 |
| package type | SC-70 |
| packaging | Tape and Reel |
| packaging: | Reel, Cut Tape |
| партномер | 8005003045 |
| part status | active |
| pcb changed | 5 |
| pin count | 5 |
| power supply type | Single|Dual |
| ppap | No |
| product: | Operational Amplifiers |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| rail to rail | Rail to Rail Input/Output |
| reach status | REACH Unaffected |
| series: | OPA1671 |
| shutdown: | No Shutdown |
| slew rate | 5V/Вµs |
| sr - slew rate: | 5 V/us |
| standard package name | SOT |
| subcategory: | Amplifier ICs |
| supplier device package | SC-70-5 |
| supplier package | SC-70 |
| supplier temperature grade | Extended Industrial |
| supply voltage - max: | 5.5 V, +/-2.75 V |
| supply voltage - min: | 1.7 V, +/-850 mV |
| thdn | 0.00035%@10000Ohm |
| thd plus noise: | 0.00035% |
| typical gain bandwidth product (mhz) | 13 |
| typical single supply voltage | 5 V |
| typical single supply voltage (v) | 3|5 |
| вес, г | 0.01 |
| voltage - input offset | 250ВµV |
| voltage - supply, single/dual (в±) | 1.7V ~ 5.5V, В±0.85V ~ 2.75V |
| vos - input offset voltage: | 250 uV |
