| Информация о производителе | |
| Производитель | Analog Devices |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 21:49:10 |
| Бренд | Analog Devices |
| Вес и габариты | |
| amplifier type | General Purpose |
| amplifier type: | General Purpose Amplifier |
| base product number | OP295 -> |
| частота | единичного усиления 0.085 МГц |
| cmrr - common mode rejection ratio: | 110 dB |
| current - input bias | 7nA |
| current - output / channel | 25mA |
| dual supply voltage | +/-3 V, +/-5 V, +/-9 V, +/-12 V, +/-15 V |
| dual supply voltage: | +/-3 V, +/-5 V, +/-9 V, +/-12 V, +/-15 V |
| eccn | EAR99 |
| en - input voltage noise density | 51 nV/sqrt Hz |
| en - input voltage noise density: | 51 nV/sqrt Hz |
| factory pack quantity | 98 |
| factory pack quantity: factory pack quantity: | 98 |
| gain bandwidth product | 75kHz |
| gbp - gain bandwidth product | 85 kHz |
| gbp - gain bandwidth product: | 85 kHz |
| htsus | 8542.33.0001 |
| ib - input bias current | 0.02 uA |
| ib - input bias current: | 20 nA |
| in - input noise current density | 0.1 pA/sqrt Hz |
| in - input noise current density: | 0.1 pA/sqrt Hz |
| категория | Электронные компоненты/Микросхемы |
| характеристика | Токовое смещение на входе 7 нА |
| количество | каналов 2 |
| manufacturer | Analog Devices Inc. |
| manufacturer: | Analog Devices Inc. |
| maximum dual supply voltage | +/-18 V |
| maximum dual supply voltage: | +/-18 V |
| maximum operating temperature | +125 C |
| maximum operating temperature: | +125 C |
| minimum dual supply voltage | +/-1.5 V |
| minimum dual supply voltage: | +/-1.5 V |
| minimum operating temperature | -40 C |
| minimum operating temperature: | -40 C |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| напряжение | смещения на входе 300 мкВ |
| напряжение питания | однополярное(+)/двуполярное(±)+3…36, ±1.5…18 В |
| number of channels | 2 Channel |
| number of channels: | 2 Channel |
| number of circuits | 2 |
| operating supply current | 300 uA |
| operating supply current: | 300 uA |
| operating supply voltage | 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 28 V |
| operating supply voltage: | 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 28 V |
| operating temperature | -40В°C ~ 125В°C |
| output current per channel: | 5 nA |
| output type | Rail-to-Rail |
| output type: | Rail-to-Rail |
| package | Tube |
| package / case | 8-SOIC (0.154"", 3.90mm Width) |
| package / case: | SOIC-8 |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8004980430 |
| product | Operational Amplifiers |
| product: | Operational Amplifiers |
| product category | Operational Amplifiers-Op Amps |
| product category: | Operational Amplifiers-Op Amps |
| product type | Op Amps-Operational Amplifiers |
| product type: | Op Amps-Operational Amplifiers |
| psrr - power supply rejection ratio | 90 dB |
| psrr - power supply rejection ratio: | 90 dB |
| рабочая температура | -40…+85 °С |
| reach status | REACH Unaffected |
| rohs status | ROHS3 Compliant |
| series | OP295 |
| series: | OP295 |
| shutdown | No Shutdown |
| shutdown: | No Shutdown |
| скорость | нарастания выходного сигнала 0.03 В/мкс |
| slew rate | 0.03V/Вµs |
| sr - slew rate | 0.03 V/us |
| sr - slew rate: | 30 mV/us |
| subcategory | Amplifier ICs |
| subcategory: | Amplifier ICs |
| supplier device package | 8-SOIC |
| supply type | Single, Dual |
| supply type: | Single, Dual |
| supply voltage - max | 36 V |
| supply voltage - max: | 36 V, +/-18 V |
| supply voltage - min | 3 V |
| supply voltage - min: | 3 V, +/-1.5 V |
| technology | BiCMOS |
| technology: | BiCMOS |
| ток | собственного потребления 0.175 мА |
| Тип | усилителя общего применения |
| type | General Purpose Amplifier |
| type: | General Purpose Amplifier |
| вес, г | 0.54 |
| voltage gain db | 140 dB |
| voltage gain db: | 140 dB |
| voltage - input offset | 300ВµV |
| voltage - supply, single/dual (в±) | 3V ~ 36V, В±1.5V ~ 18V |
| vos - input offset voltage | 300 uV |
| vos - input offset voltage: | 300 uV |
| выходной ток | на канал 25 мА |
