OP291GSZ, Operational Amplifiers - Op Amps RAIL-RAIL SINGLE SUPPLY
Оставить отзыв
В избранноеВ сравнение
Артикул: OP291GSZ
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Semiconductors\Amplifier ICs\Operational Amplifiers - Op Amps Описание IC: operational amplifier; 3MHz; Ch: 2; SO8; ±1.35?6VDC,2.7?12VDC Характеристики Категория
Микросхема
Тип
операционный усилитель
Монтаж
SMD
Кол-во каналов
2
| Информация о производителе | |
| Производитель | Analog Devices |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 21:49:14 |
| Бренд | Analog Devices |
| Вес и габариты | |
| amplifier type | General Purpose |
| amplifier type: | General Purpose Amplifier |
| bandwidth | 3 MHz |
| base product number | OP291 -> |
| cmrr - common mode rejection ratio: | 90 dB |
| common mode rejection ratio | 100 dB |
| contact plating | Tin |
| current - input bias | 30nA |
| current - output / channel | 16mA |
| current - supply | 260ВµA (x2 Channels) |
| диапазон напряжения питания | 2.7В до 12В |
| dual supply voltage | +/-3 V, +/-5 V |
| dual supply voltage: | +/-3 V, +/-5 V |
| eccn | EAR99 |
| eccn (us) | ear99 |
| en - input voltage noise density | 42 nV/sqrt Hz |
| en - input voltage noise density: | 42 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity | 1000 |
| factory pack quantity: factory pack quantity: | 98 |
| gain bandwidth product | 3MHz |
| gbp - gain bandwidth product | 3 MHz |
| gbp - gain bandwidth product: | 3 MHz |
| height | 1.5 mm(Max) |
| hts | 8542.33.00.01 |
| htsus | 8542.33.0001 |
| ib - input bias current | 0.065 uA |
| ib - input bias current: | 65 nA |
| input bias current | 30 nA |
| input type | Rail to Rail |
| input type: | Rail-to-Rail |
| in - input noise current density | 0.8 pA/sqrt Hz |
| in - input noise current density: | 0.8 pA/sqrt Hz |
| категория | Электронные компоненты/Микросхемы |
| количество усилителей | 2 Усилителя |
| количество выводов | 8вывод(-ов) |
| lead shape | Gull-wing |
| length | 5 mm(Max) |
| максимальная рабочая температура | 125 C |
| manufacturer | Analog Devices Inc. |
| manufacturer: | Analog Devices Inc. |
| manufacturer type | Micropower Amplifier |
| maximum dual supply voltage | +/-6 V |
| maximum dual supply voltage: | +/-6 V |
| maximum dual supply voltage (v) | ±6 |
| maximum input bias current (ua) | 0.065@5V |
| maximum input offset current (ua) | 0.011@5V |
| maximum input offset voltage (mv) | 0.7@5V |
| maximum operating temperature | +125 C |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum single supply voltage (v) | 12 |
| maximum supply current (ma) | 0.8@5V |
| минимальная рабочая температура | -40 C |
| minimum cmrr (db) | 70 |
| minimum cmrr range (db) | 70 to 71 |
| minimum dual supply voltage | +/-1.35 V |
| minimum dual supply voltage: | +/-1.35 V |
| minimum dual supply voltage (v) | ±1.35 |
| minimum operating temperature | -40 C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 80 |
| minimum single supply voltage (v) | 02.07.2024 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting | surface mount |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels | 2 Channel |
| number of channels: | 2 Channel |
| number of channels per chip | 2 |
| number of circuits | 2 |
| number of elements | 2 |
| number of pins | 8 |
| operating supply current | 800 uA |
| operating supply current: | 800 uA |
| operating supply voltage | 3 V, 5 V, 9 V |
| operating supply voltage: | 3 V, 5 V, 9 V |
| operating temperature | -40В°C ~ 125В°C |
| output current per channel | 16 mA |
| output current per channel: | 11 nA |
| output type | Rail-to-Rail |
| output type: | Rail-to-Rail |
| package | Tube |
| package / case | 8-SOIC (0.154"", 3.90mm Width) |
| package / case: | SOIC-8 |
| package height | 1.5(Max) |
| package length | 5(Max) |
| package width | 4(Max) |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8004980425 |
| part status | active |
| pcb changed | 8 |
| pin count | 8 |
| полоса пропускания | 3МГц |
| power supply type | Single|Dual |
| process technology | Bipolar |
| product | Operational Amplifiers |
| product: | Operational Amplifiers |
| product category | Operational Amplifiers-Op Amps |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| psrr - power supply rejection ratio | 80 dB |
| psrr - power supply rejection ratio: | 80 dB |
| quiescent current | 420 µA |
| rail to rail | Rail to Rail Input/Output |
| reach status | REACH Unaffected |
| rohs | Details |
| rohs status | ROHS3 Compliant |
| series | OP291 |
| series: | OP291 |
| settling time | 22 µs |
| shutdown | No Shutdown |
| shutdown: | No Shutdown |
| shut down support | No |
| скорость нарастания | 0.5В/мкс |
| slew rate | 0.5V/Вµs |
| sr - slew rate | 0.4 V/us |
| sr - slew rate: | 400 mV/us |
| standard package name | SOP |
| стиль корпуса усилителя | NSOIC |
| subcategory: | Amplifier ICs |
| supplier device package | 8-SOIC |
| supplier package | SOIC N |
| supplier temperature grade | Extended Industrial |
| supply type | Single, Dual |
| supply type: | Single, Dual |
| supply voltage - max | 12 V |
| supply voltage - max: | 12 V, +/-6 V |
| supply voltage - min | 2.7 V |
| supply voltage - min: | 2.7 V, +/-1.35 V |
| technology | Bipolar |
| technology: | Bipolar |
| type | Micropower Amplifier |
| type: | General Purpose Amplifier |
| typical dual supply voltage (v) | ±3|±5 |
| typical gain bandwidth product (mhz) | 3 |
| typical input noise voltage density (nv/rthz) | 42@5V |
| typical noninverting input current noise density (pa/rthz) | 0.8@5V |
| typical settling time (ns) | 22000 |
| typical single supply voltage (v) | 3|5|9 |
| typical slew rate (v/us) | 0.4@5V |
| typical voltage gain (db) | 96.9 |
| unit weight | 0.019048 oz |
| уровень чувствительности к влажности (msl) | MSL 1-Безлимитный |
| вес, г | 0.54 |
| voltage gain db | 96.9 dB |
| voltage gain db: | 96.9 dB |
| voltage - input offset | 80ВµV |
| voltage - supply, single/dual (в±) | 2.7V ~ 12V, В±1.35V ~ 6V |
| vos - input offset voltage | 700 uV |
| vos - input offset voltage: | 700 uV |
| width | 4 mm(Max) |
