| Информация о производителе | |
| Производитель | Microchip Technology |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 2:50:05 |
| Бренд | Microchip Technology |
| Вес и габариты | |
| amplifier type | Precision |
| automotive | Yes |
| common mode rejection ratio | 75(dB) |
| диапазон напряжения питания | 2.5В до 5.5В |
| dual supply voltage (max) | Not Required(V) |
| dual supply voltage (min) | Not Required(V) |
| dual supply voltage (typ) | Not Required(V) |
| eccn (us) | ear99 |
| eu rohs | compliant |
| input bias current | 0.001(nA) |
| input offset voltage | 0.25(mV) |
| категория | Электронные компоненты/Микросхемы |
| количество усилителей | 4 Усилителя |
| количество выводов | 14вывод(-ов) |
| lead shape | Gull-wing |
| максимальная рабочая температура | 125°C |
| manufacturer type | Micropower Amplifier |
| maximum input offset current | 0.000001(TYP)@5.5V |
| maximum input offset current (ua) | 0.000001(Typ)5.5V |
| maximum input offset voltage (mv) | 0.25 5.5V |
| maximum operating temperature | +85 °C |
| maximum operating temperature (°c) | 85 |
| maximum quiescent current (ma) | 0.1 5.5V |
| maximum single supply voltage (v) | 6 |
| минимальная рабочая температура | -40°C |
| minimum cmrr (db) | 75 |
| minimum cmrr range (db) | 75 to 80 |
| minimum operating temperature | -40 °C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 80 |
| minimum single supply voltage (v) | 02.05.2024 |
| mounting | surface mount |
| mounting type | Surface Mount |
| number of channels per chip | 4 |
| number of elements | 4 |
| operating temperature classification | Industrial |
| operating temp range | -40C to 85C |
| output type | CMOS |
| package type | TSSOP |
| packaging | Tube |
| партномер | 8016844797 |
| part status | active |
| pcb changed | 14 |
| pin count | 14 |
| полоса пропускания | 155кГц |
| power supply rejection ratio | 80(dB) |
| power supply requirement | Single |
| power supply type | Single |
| ppap | Yes |
| process technology | CMOS |
| rad hardened | No |
| rail/rail i/o type | Rail to Rail Output |
| rail to rail | Rail to Rail Output |
| shut down feature | No |
| shut down support | No |
| single supply voltage (max) | 6(V) |
| single supply voltage (min) | 2.5(V) |
| single supply voltage (typ) | 3/5(V) |
| скорость нарастания | 0.08В/мкс |
| slew rate | 0.08(V/us) |
| standard package name | SOP |
| стиль корпуса усилителя | TSSOP |
| supplier package | TSSOP |
| supplier temperature grade | Industrial |
| technology | CMOS |
| type | Micropower Amplifier |
| typical gain bandwidth product | 155kHz |
| typical gain bandwidth product (mhz) | 0.155 |
| typical input bias current (ua) | 0.000001 5.5V |
| typical input noise voltage density (nv/rthz) | 38 5.5V |
| typical input voltage noise density | 38nV/√Hz |
| typical noninverting input current noise density (pa/rthz) | 0.003 5.5V |
| typical output current (ma) | 30(Max) |
| typical single supply voltage | 3 V, 5 V |
| typical single supply voltage (v) | 3|5 |
| typical slew rate | 0.08V/µs |
| typical slew rate (v/us) | 0.08 5.5V |
| typical voltage gain | 121 dB |
| typical voltage gain (db) | 121 |
| unity gain bandwidth product | 0.155 |
| уровень чувствительности к влажности (msl) | MSL 1-Безлимитный |
| вес, г | 0.12 |
| voltage gain in db | 121(dB) |
| width | 4.4mm |
