| Информация о производителе | |
| Производитель | Microchip Technology |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 0:30:40 |
| Бренд | Microchip Technology |
| Вес и габариты | |
| amplifier type | General Purpose |
| automotive | Yes |
| common mode rejection ratio | 60(dB) |
| dual supply voltage (max) | Not Required(V) |
| dual supply voltage (min) | Not Required(V) |
| dual supply voltage (typ) | Not Required(V) |
| eccn (us) | ear99 |
| eu rohs | compliant |
| gbp - gain bandwidth product | 14kHz |
| input bias current | 0.001(nA) |
| input offset current | 1pA |
| input offset voltage | 3(mV) |
| input voltage range | 1.4 → 6 V |
| iq per channel (typ) | 600nA |
| категория | Электронные компоненты/Микросхемы |
| lead shape | Gull-wing |
| manufacturer type | General Purpose Amplifier |
| maximum input offset current | 0.000001(TYP)@5.5V |
| maximum input offset current (ua) | 0.000001(Typ)@5.5V |
| maximum input offset voltage (mv) | 3@5.5V |
| maximum input voltage | 6 V |
| maximum operating temperature | 85В°C |
| maximum operating temperature (°c) | 85 |
| maximum quiescent current (ma) | 0.002@5.5V |
| maximum single supply voltage (v) | 6 |
| minimum cmrr (db) | 60 |
| minimum cmrr range (db) | 60 to 65 |
| minimum input voltage | 1.4 V |
| minimum operating temperature | -40В°C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 70 |
| minimum single supply voltage (v) | 01.04.2024 |
| mounting | surface mount |
| mounting type | Surface Mount |
| number of channels per chip | 2 |
| number of circuits | 2 |
| number of elements | 2 |
| offset voltage | ±3mV |
| operating temperature classification | Industrial |
| operating temp range | -40C to 85C |
| output current | ±30 mA |
| output type | Rail-to-Rail |
| package type | SOIC N |
| packaging | Tape and Reel |
| партномер | 8002985195 |
| part status | active |
| pcb changed | 8 |
| pin count | 8 |
| power supply rejection ratio | 70(dB) |
| power supply requirement | Single |
| power supply type | Single |
| ppap | Yes |
| process technology | CMOS |
| rad hardened | No |
| rail to rail | Rail to Rail Input/Output |
| shut down feature | No |
| shut down support | No |
| single supply voltage (max) | 6(V) |
| single supply voltage (min) | 1.4(V) |
| single supply voltage (typ) | 3/5(V) |
| slew rate | 0.003(V/us) |
| sr - slew rate | 0.003 V/us |
| standard package name | SO |
| supplier package | SOIC N |
| supplier temperature grade | Industrial |
| supply voltage - max | 6V |
| supply voltage - min | 1.4V |
| technology | CMOS |
| type | General Purpose Amplifier |
| typical gain bandwidth product | 14kHz |
| typical gain bandwidth product (mhz) | 0.014 |
| typical input bias current (ua) | 0.000001@5.5V |
| typical input noise voltage density (nv/rthz) | 170@5.5V |
| typical input voltage noise density | 170nV/√Hz |
| typical noninverting input current noise density (pa/rthz) | 0.0006@5.5V |
| typical output current (ma) | 30(Max) |
| typical slew rate | 3V/ms |
| typical slew rate (v/us) | 0.003@5.5V |
| typical voltage gain | 115 dB |
| typical voltage gain (db) | 115 |
| unity gain bandwidth product | 0.014 |
| voltage gain in db | 115(dB) |
| width | 3.9mm |
