LT1990IMS8-10
Оставить отзыв
В избранноеВ сравнение
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
ЭлектроэлементSP Amp Difference Amplifier Single R-R O/P ±18V/36V 8-Pin MSOP Tube
| Информация о производителе | |
| Производитель | Analog Devices |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 23:18:40 |
| Бренд | Analog Devices |
| Вес и габариты | |
| 3 db bandwidth: | 100 kHz |
| automotive | No |
| cmrr - common mode rejection ratio: | 68 dB |
| common mode rejection ratio | 60(dB) |
| dual supply voltage (max) | ±18(V) |
| dual supply voltage (min) | ±1.35(V) |
| eccn (us) | ear99 |
| en - input voltage noise density: | 1 uV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 50 |
| gain error | 0.2% |
| gbp - gain bandwidth product: | 100 kHz |
| input offset voltage | 3(mV) |
| input resistance | 2(MOhm) |
| категория | Электронные компоненты/Микросхемы |
| lead shape | Gull-wing |
| manufacturer: | Analog Devices Inc. |
| maximum dual supply voltage (v) | ±18 |
| maximum input offset voltage (mv) | 3@5V |
| maximum input resistance (mohm) | 2(Typ)@5V |
| maximum operating supply voltage (v) | ±18|36 |
| maximum operating temperature: | +85 C |
| maximum operating temperature (°c) | 85 |
| maximum single supply voltage (v) | 36 |
| maximum supply current (ma) | 0.18@5V |
| maximum supply voltage range (v) | 30 to 50 |
| minimum cmrr (db) | 60 |
| minimum cmrr range (db) | 60 to 75 |
| minimum dual supply voltage (v) | ±1.35 |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 80 |
| minimum single supply voltage (v) | 02.07.2024 |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| number of channels | 1 |
| number of channels: | 1 Channel |
| number of channels per chip | 1 |
| number of elements | 1 |
| number of elements per chip | 1 |
| operating supply current: | 105 uA |
| operating temperature classification | Industrial |
| operating temp range | -40C to 85C |
| output current per channel: | 20 mA |
| output type: | Rail-to-Rail |
| package/case: | MSOP-8 |
| package type | MSOP |
| packaging | Rail/Tube |
| packaging: | Tube |
| партномер | 8011048142 |
| part status | active |
| pcb changed | 8 |
| pin count | 8 |
| power supply rejection ratio | 80(dB) |
| power supply requirement | Single/Dual |
| power supply type | Single|Dual |
| ppap | No |
| product: | Differential Amplifiers |
| product category: | Differential Amplifiers |
| product type: | Differential Amplifiers |
| psrr - power supply rejection ratio: | 92 dB |
| rad hardened | No |
| rail/rail i/o type | Rail to Rail Output |
| rail to rail | Rail to Rail Output |
| series: | LT1990-10 |
| settling time: | 20 us |
| shutdown: | No Shutdown |
| single supply voltage (max) | 36(V) |
| single supply voltage (min) | 2.7(V) |
| single supply voltage (typ) | 3/5/9/12/15/18/24/28(V) |
| sr - slew rate: | 0.5 V/us |
| standard package name | SOP |
| subcategory: | Amplifier ICs |
| supplier package | MSOP |
| supplier temperature grade | Industrial |
| supply voltage - max: | 36 V |
| supply voltage - min: | 2.7 V |
| type | Difference Amplifier |
| typical dual supply voltage (v) | ±15 |
| typical single supply voltage (v) | 3|5 |
| vcm - common mode voltage: | 47 V |
| vos - input offset voltage: | 800 uV |
