| Информация о производителе | |
| Производитель | STMicroelectronics |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 1:03:37 |
| Бренд | STMicroelectronics |
| Вес и габариты | |
| amplifier type | Low Power |
| amplifier type: | Low Power Amplifier |
| automotive | No |
| cmrr - common mode rejection ratio: | 90 dB |
| eccn (us) | ear99 |
| en - input voltage noise density: | 18 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 4000 |
| gbp - gain bandwidth product: | 5.5 MHz |
| ib - input bias current: | 180 nA |
| input offset voltage drift (uv/°c) | 1(Typ) |
| категория | Электронные компоненты/Микросхемы |
| lead shape | Gull-wing |
| manufacturer: | STMicroelectronics |
| manufacturer type | Low Power Amplifier |
| maximum input bias current (ua) | 0.12@5V |
| maximum input offset current (ua) | 0.03@5V |
| maximum input offset voltage (mv) | 0.8@5V |
| maximum operating temperature | +125 °C |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum quiescent current (ma) | 0.8@5V |
| maximum single supply voltage (v) | 05.05.2024 |
| minimum cmrr (db) | 72 |
| minimum cmrr range (db) | 71 to 75 |
| minimum operating temperature | -40 °C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum single supply voltage (v) | 02.05.2024 |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels: | 2 Channel |
| number of channels per chip | 2 |
| operating supply current: | 300 uA |
| operating supply voltage: | 2.5 V to 5.5 V |
| output current per channel: | 26 mA |
| package / case: | MiniSO-8 |
| package type | MSOP |
| packaging | Tape and Reel |
| партномер | 8004826472 |
| part status | active |
| pcb changed | 8 |
| pin count | 8 |
| power supply type | Single |
| ppap | No |
| product: | Operational Amplifiers |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| rail to rail | Rail to Rail Output |
| series: | LMV822A |
| shutdown: | No Shutdown |
| shut down support | No |
| sr - slew rate: | 1.7 V/us |
| standard package name | SOP |
| subcategory: | Amplifier ICs |
| supplier package | Mini-SO |
| supplier temperature grade | Extended |
| supply type: | Single |
| supply voltage - max: | 5.5 V |
| supply voltage - min: | 2.5 V |
| type | Low Power Amplifier |
| typical gain bandwidth product | 5.5MHz |
| typical gain bandwidth product (mhz) | 05.05.2024 |
| typical high level output voltage (v) | 0.25 |
| typical input bias current (ua) | 0.06@5V |
| typical input noise voltage density (nv/rthz) | 16@5V |
| typical input voltage noise density | 18nV/√Hz |
| typical low level output voltage (v) | 0.25 |
| typical noninverting input current noise density (pa/rthz) | 0.3@5V |
| typical output current (ma) | 70@5V |
| typical single supply voltage | 2.5 → 5.5 V |
| typical slew rate | 1.7V/µs |
| typical slew rate (v/us) | 1.9@5V |
| typical voltage gain | 100 dB |
| typical voltage gain (db) | 100 |
| вес, г | 0.02 |
| vos - input offset voltage: | 2 mV |
| width | 3.1mm |
