LM324NE3, LM324NE3 , Quad, Op Amps Rail to Rail Input, 1.2MHz, 32 V, 14-Pin PDIP
Оставить отзыв
В избранноеВ сравнение
Артикул: LM324NE3
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Semiconductors\Amplifiers & Comparators\Op AmpsThe Texas Instruments operational amplifiers provides outstanding value for cost sensitive applications.
| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 2:31:52 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| amplifier type | Quad |
| cmrr - common mode rejection ratio | 65 dB to 80 dB |
| cmrr - common mode rejection ratio: | 80 dB |
| en - input voltage noise density | 35 nV/sqrt Hz |
| en - input voltage noise density: | 35 nV/sqrt Hz |
| factory pack quantity | 25 |
| factory pack quantity: factory pack quantity: | 25 |
| features: | Standard Amps |
| gbp - gain bandwidth product | 1.2 MHz |
| gbp - gain bandwidth product: | 1.2 MHz |
| ib - input bias current | 250 nA |
| ib - input bias current: | 250 nA |
| input type | Rail-to-Rail |
| input type: | Rail-to-Rail |
| категория | Электронные компоненты/Микросхемы |
| manufacturer | Texas Instruments |
| manufacturer: | Texas Instruments |
| maximum operating temperature | +70 C |
| maximum operating temperature: | +70 C |
| minimum dual supply voltage | +/-1.5 V |
| minimum dual supply voltage: | +/-1.5 V |
| minimum operating temperature | 0 C |
| minimum operating temperature: | 0 C |
| mounting style | Through Hole |
| mounting style: | Through Hole |
| mounting type | Through Hole |
| number of channels | 4 Channel |
| number of channels: | 4 Channel |
| number of channels per chip | 4 |
| operating supply current | 175 uA |
| operating supply current: | 1.4 mA |
| operating supply voltage | 3 V to 32 V |
| operating supply voltage: | 3 V to 32 V |
| output current per channel | 30 mA |
| output current per channel: | 20 mA |
| package / case | PDIP-14 |
| package/case: | PDIP-14 |
| package type | PDIP |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8030993278 |
| pin count | 14 |
| power supply type | Dual, Single |
| product | Operational Amplifiers |
| product: | Operational Amplifiers |
| product category | Operational Amplifiers-Op Amps |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| rail to rail | Rail to Rail Input |
| rohs | Details |
| series | LM324 |
| series: | LM324 |
| shutdown | No Shutdown |
| shutdown: | No Shutdown |
| sr - slew rate | 0.5 V/us |
| sr - slew rate: | 500 mV/us |
| subcategory: | Amplifier ICs |
| supply type | Single, Dual |
| supply type: | Single, Dual |
| supply voltage - max | 32 V |
| supply voltage - max: | 32 V |
| supply voltage - min | 3 V |
| supply voltage - min: | 3 V |
| typical gain bandwidth product | 1.2MHz |
| typical single supply voltage | 32 V |
| unit weight | 0.032734 oz |
| vcm - common mode voltage | 3 V to 32 V |
| vcm - common mode voltage: | 3 V to 32 V |
| vos - input offset voltage | 7 mV |
| vos - input offset voltage: | 7 mV |
