| Информация о производителе | |
| Производитель | DIODES INC. |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 3:18:45 |
| Бренд | DIODES INC. |
| Вес и габариты | |
| amplifier type: | Operational |
| automotive | Yes |
| cmrr - common mode rejection ratio: | 70 dB |
| eccn (us) | ear99 |
| en - input voltage noise density: | 40 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 2500 |
| gbp - gain bandwidth product: | 700 kHz |
| ib - input bias current: | 20 nA |
| ios - input offset current: | 2 nA |
| категория | Электронные компоненты/Микросхемы |
| manufacturer: | Diodes Incorporated |
| manufacturer type | General Purpose Amplifier |
| maximum dual supply voltage (v) | ±18 |
| maximum input bias current (ua) | 0.2@5V |
| maximum input offset current (ua) | 0.05@5V |
| maximum input offset voltage (mv) | 2@5V |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum quiescent current (ma) | 1.2@5V@-40C to 85C |
| maximum single supply voltage (v) | 36 |
| minimum cmrr (db) | 60 |
| minimum cmrr range (db) | 60 to 65 |
| minimum dual supply voltage (v) | ±1.5 |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 70 |
| minimum single supply voltage (v) | 3 |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| number of channels: | 4 Channel |
| number of channels per chip | 4 |
| operating supply current: | 700 uA |
| output current per channel: | 40 mA |
| package / case: | TSSOP-14 |
| packaging | Tape and Reel |
| партномер | 8017651694 |
| part status | active |
| pcb changed | 14 |
| pin count | 14 |
| power supply type | Single|Dual |
| ppap | Yes |
| process technology | Bipolar |
| product: | Operational Amplifiers |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| psrr - power supply rejection ratio: | 100 dB |
| qualification: | AEC-Q100 |
| shutdown: | No Shutdown |
| shut down support | No |
| sr - slew rate: | 300 mV/us |
| subcategory: | Amplifier ICs |
| supplier package | TSSOP |
| supplier temperature grade | Automotive |
| supply voltage - max: | 36 V, +/-18 V |
| supply voltage - min: | 3 V, +/-1.5 V |
| type | General Purpose Amplifier |
| typical dual supply voltage (v) | ±3|±5|±9|±12|±15 |
| typical gain bandwidth product (mhz) | 0.7 |
| typical input bias current (ua) | 0.02@5V |
| typical input noise voltage density (nv/rthz) | 40@±15V |
| typical output current (ma) | 50@15V |
| typical slew rate (v/us) | 0.3@±15V |
| typical voltage gain (db) | 100 |
| вес, г | 0.22 |
| vos - input offset voltage: | 2 mV |
