| Информация о производителе | |
| Производитель | Renesas Technology |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 23:19:45 |
| Бренд | Renesas Technology |
| Вес и габариты | |
| amplifier type: | General Purpose Amplifier |
| cmrr - common mode rejection ratio: | 70 dB |
| dual supply voltage: | +/-3 V, +/-5 V, +/-9 V, +/-12 V, +/-15 V |
| en - input voltage noise density: | 40 nV/sqrt Hz |
| factory pack quantity: factory pack quantity: | 980 |
| gbp - gain bandwidth product: | 4.5 MHz |
| ib - input bias current: | 40 pA |
| категория | Электронные компоненты/Микросхемы |
| manufacturer: | Renesas Electronics |
| maximum dual supply voltage: | +/-18 V |
| maximum operating temperature | +125 °C |
| maximum operating temperature: | +125 C |
| minimum dual supply voltage: | +/-2 V |
| minimum operating temperature | -55 °C |
| minimum operating temperature: | -55 C |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels: | 1 Channel |
| number of channels per chip | 1 |
| operating supply current: | 1.6 mA |
| operating supply voltage: | 4 V to 36 V, +/-2 V to+/-18 V |
| output current per channel: | 40 mA |
| package / case: | SOIC-8 |
| package type | SOIC |
| packaging: | Tube |
| партномер | 8004744118 |
| pin count | 8 |
| power supply type | Dual, Single |
| product: | Operational Amplifiers |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| psrr - power supply rejection ratio: | 80 dB(Typ) |
| rail to rail | No |
| series: | CA3140A |
| shutdown: | No Shutdown |
| sr - slew rate: | 9 V/us |
| subcategory: | Amplifier ICs |
| supply type: | Single, Dual |
| supply voltage - max: | 36 V, +/-18 V |
| supply voltage - min: | 4 V, +/-2 V |
| technology: | BiCMOS |
| typical dual supply voltage | ±12 V, ±15 V, ±3 V, ±5 V, ±9 V |
| typical gain bandwidth product | 3.7MHz |
| typical input voltage noise density | 40nV/√Hz |
| typical single supply voltage | 5 → 28 V |
| typical slew rate | 7V/µs |
| typical voltage gain | 100 dB |
| вес, г | 0.07 |
| voltage gain db: | 100 dB |
| vos - input offset voltage: | 5 mV |
| width | 4mm |
