| Информация о производителе | |
| Производитель | Analog Devices |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 21:58:08 |
| Бренд | Analog Devices |
| Вес и габариты | |
| amplifier type: | Low Power Amplifier |
| automotive | No |
| cmrr - common mode rejection ratio: | 115 dB |
| диапазон напряжения питания | 2.7В до 12В |
| dual supply voltage: | +/-3 V, +/-5 V |
| eccn (us) | ear99 |
| en - input voltage noise density: | 2.1 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 1500 |
| gbp - gain bandwidth product: | 35 MHz |
| ib - input bias current: | 5.3 uA |
| in - input noise current density: | 1.4 pA/sqrt Hz |
| категория | Электронные компоненты/Микросхемы |
| количество усилителей | 2 Усилителя |
| количество выводов | 8вывод(-ов) |
| lead shape | no lead |
| линейка продукции | - |
| максимальная рабочая температура | 125°C |
| manufacturer: | Analog Devices Inc. |
| manufacturer type | Low Noise Amplifier |
| maximum dual supply voltage: | +/-6 V |
| maximum dual supply voltage (v) | ±6 |
| maximum input bias current (ua) | 5.3 5V |
| maximum input offset current (ua) | 0.4 5V |
| maximum input offset voltage (mv) | 0.3 5V |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum single supply voltage (v) | 12 |
| минимальная рабочая температура | -40°C |
| minimum cmrr (db) | 88 |
| minimum cmrr range (db) | 85 to 90 |
| minimum dual supply voltage: | +/-1.35 V |
| minimum dual supply voltage (v) | ±1.35 |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 95 |
| minimum single supply voltage (v) | 02.07.2024 |
| moisture sensitive: | Yes |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| number of channels: | 2 Channel |
| number of channels per chip | 2 |
| operating supply current: | 3 mA |
| operating supply voltage: | 2.7 V to 12 V |
| output current per channel: | 30 mA |
| output type: | Rail-to-Rail |
| package / case: | LFCSP-8 |
| packaging | Tape and Reel |
| партномер | 8016878222 |
| part status | active |
| pcb changed | 8 |
| pin count | 8 |
| полоса пропускания | 80МГц |
| power supply type | Single|Dual |
| ppap | No |
| process technology | XFCB |
| product: | Operational Amplifiers |
| product category: | Operational Amplifiers-Op Amps |
| product type: | Op Amps-Operational Amplifiers |
| psrr - power supply rejection ratio: | 110 dB |
| rail to rail | Rail to Rail Output |
| series: | ADA4841-2 |
| shutdown: | No Shutdown |
| shut down support | No |
| скорость нарастания | 13В/мкс |
| sr - slew rate: | 12 V/us |
| standard package name | CSP |
| стандарты автомобильной промышленности | - |
| стиль корпуса усилителя | LFCSP |
| subcategory: | Amplifier ICs |
| supplier package | LFCSP EP |
| supplier temperature grade | Industrial |
| supply type: | Single, Dual |
| supply voltage - max: | 12 V, +/-6 V |
| supply voltage - min: | 2.7 V, +/-1.35 V |
| technology: | Bipolar |
| type | Low Noise Amplifier |
| type: | Voltage Feedback Amplifier |
| typical dual supply voltage (v) | ±3|±5 |
| typical gain bandwidth product (mhz) | 35 |
| typical input noise voltage density (nv/rthz) | 2.1 5V |
| typical noninverting input current noise density (pa/rthz) | 1.4 5V |
| typical output current (ma) | 60 5V |
| typical settling time (ns) | 550 |
| typical single supply voltage (v) | 9|5|3 |
| typical slew rate (v/us) | 12 5V |
| typical voltage gain (db) | 124 |
| уровень чувствительности к влажности (msl) | MSL 3-168 часов |
| вес, г | 0.5 |
| voltage gain db: | 120 dB |
| vos - input offset voltage: | 40 uV |
