AD8538ARZ, Precision Amplifiers Low Power, Precision, Auto-Zero Op Amp (5-lead TSOT-23)
Оставить отзыв
В избранноеВ сравнение
Артикул: AD8538ARZ
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Semiconductors\Amplifier ICs\Precision AmplifiersAmplifiers ADI SLP
| Информация о производителе | |
| Производитель | Analog Devices |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 22:38:54 |
| Бренд | Analog Devices |
| Вес и габариты | |
| amplifier type | Zero-Drift |
| base product number | AD8538 -> |
| category | Integrated Circuits(ICs) |
| cmrr - common mode rejection ratio: | 150 dB |
| current - input bias | 15pA |
| current - output / channel | 25mA |
| current - output/channel | 25mA |
| current - supply | 150ВµA |
| dual supply voltage: | 1.35 V to 2.5 V |
| eccn | EAR99 |
| eccn (us) | ear99 |
| en - input voltage noise density: | 50 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 98 |
| family | Amplifiers-Instrumentation, OP Amps, Buffer Amps |
| gain bandwidth product | 430kHz |
| gbp - gain bandwidth product: | 430 kHz |
| hts | 8542.33.00.01 |
| htsus | 8542.33.0001 |
| ib - input bias current: | 25 pA |
| input offset voltage drift (uv/°c) | 0.1 |
| input voltage range - max: | 5 V |
| категория | Электронные компоненты/Микросхемы |
| lead shape | Gull-wing |
| manufacturer: | Analog Devices Inc. |
| manufacturer type | Precision Amplifier |
| maximum dual supply voltage: | 2.5 V |
| maximum dual supply voltage (v) | ±2.5 |
| maximum input bias current (ua) | 0.000025@5V |
| maximum input offset current (ua) | 0.00005@5V |
| maximum input offset voltage (mv) | 0.013@5V |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum quiescent current (ma) | 0.18@5V |
| maximum single supply voltage (v) | 5 |
| minimum cmrr (db) | 115 |
| minimum cmrr range (db) | >=115 |
| minimum dual supply voltage: | 1.35 V |
| minimum dual supply voltage (v) | ±1.35 |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 105 |
| minimum single supply voltage (v) | 02.07.2024 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels: | 1 Channel |
| number of channels per chip | 1 |
| number of circuits | 1 |
| operating supply current: | 180 uA |
| operating supply voltage: | 2.7 V to 5.5 V |
| operating temperature | -40В°C ~ 125В°C |
| other names | AD8538ARZ-REEL7 |
| output current per channel: | 25 mA |
| package | Tube |
| package / case | 8-SOIC (0.154"", 3.90mm Width) |
| package / case: | SOIC-8 |
| package height | 1.5(Max) |
| package length | 5(Max) |
| package width | 4(Max) |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8004967540 |
| part status | active |
| pcb changed | 8 |
| pin count | 8 |
| power supply type | Single|Dual |
| product: | Precision Amplifiers |
| product category: | Precision Amplifiers |
| product type: | Precision Amplifiers |
| psrr - power supply rejection ratio: | 125 dB |
| rail to rail | Rail to Rail Input/Output |
| reach status | REACH Unaffected |
| rohs status | ROHS3 Compliant |
| series: | AD8538 |
| shutdown: | No Shutdown |
| shut down support | No |
| slew rate | 0.4V/Вµs |
| sr - slew rate: | 400 mV/us |
| standard package | 1 |
| standard package name | SOP |
| subcategory: | Amplifier ICs |
| supplier device package | 8-SOIC |
| supplier package | SOIC N |
| supplier temperature grade | Extended Industrial |
| supply voltage - max: | 5.5 V, 2.5 V |
| supply voltage - min: | 2.7 V, 1.35 V |
| type | PRECISION AMPLIFIER |
| type: | General Purpose Amplifier |
| typical gain bandwidth product (mhz) | 0.43 |
| typical high level output voltage (v) | 2.693 |
| typical input bias current (ua) | 0.000015@5V |
| typical input noise voltage density (nv/rthz) | 50@5V |
| typical low level output voltage (v) | 0.02 |
| typical settling time (ns) | 10000 |
| typical single supply voltage (v) | 3 |
| typical slew rate (v/us) | 0.4@5V |
| typical voltage gain (db) | 141 |
| вес, г | 0.54 |
| voltage gain db: | 141 dB |
| voltage - input offset | 5ВµV |
| voltage - supply, single/dual (в±) | 2.7V ~ 5.5V, В±1.35V ~ 2.75V |
| vos - input offset voltage: | 5 uV |
