Усилитель операционный AD8009ARZ
| Информация о производителе | |
| Производитель | Analog Devices |
| Основные | |
| Дата загрузки | 05.05.2024 |
| Время загрузки | 0:41:06 |
| Бренд | Analog Devices |
| Вес и габариты | |
| 3 db bandwidth | 1 GHz |
| 3 db bandwidth: | 1 GHz |
| amplifier type | Current Feedback |
| amplifier type: | Current Feedback |
| base product number | AD8009 -> |
| cmrr - common mode rejection ratio | 52 dB |
| cmrr - common mode rejection ratio: | 52 dB |
| current - input bias | 50ВµA |
| current - output / channel | 175mA |
| current - supply | 16mA |
| development kit | AD8009AR-EBZ |
| development kit: | AD8009AR-EBZ |
| eccn | EAR99 |
| eccn (us) | ear99 |
| en - input voltage noise density | 1.9 nV/sqrt Hz |
| en - input voltage noise density: | 1.9 nV/sqrt Hz |
| eu rohs | compliant |
| factory pack quantity | 98 |
| factory pack quantity: factory pack quantity: | 98 |
| gbp - gain bandwidth product | - |
| height | 1.75 mm |
| hts | 8542.33.00.01 |
| htsus | 8542.33.0001 |
| ib - input bias current | 50 uA |
| ib - input bias current: | 50 uA |
| input offset voltage drift (uv/°c) | 4(Typ) |
| категория | Электронные компоненты/Микросхемы |
| lead shape | Gull-wing |
| length | 5 mm |
| manufacturer | Analog Devices Inc. |
| manufacturer: | Analog Devices Inc. |
| manufacturer type | High Speed Amplifier |
| maximum dual supply voltage | +/-6 V |
| maximum dual supply voltage: | +/-6 V |
| maximum dual supply voltage (v) | ±6 |
| maximum input bias current (ua) | 150@5V |
| maximum input offset voltage (mv) | 4@5V |
| maximum operating temperature | +85 C |
| maximum operating temperature: | +85 C |
| maximum operating temperature (°c) | 85 |
| maximum power dissipation (mw) | 750 |
| maximum quiescent current (ma) | 12@5V |
| maximum single supply voltage (v) | 12 |
| minimum cmrr (db) | 50 |
| minimum cmrr range (db) | 50 to 60 |
| minimum dual supply voltage | +/-2.5 V |
| minimum dual supply voltage: | +/-2.5 V |
| minimum dual supply voltage (v) | ±2.5 |
| minimum operating temperature | -40 C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum psrr (db) | 64 |
| minimum single supply voltage (v) | 5 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting | surface mount |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels | 1 Channel |
| number of channels: | 1 Channel |
| number of channels per chip | 1 |
| number of circuits | 1 |
| operating supply current | 16 mA |
| operating supply current: | 16 mA |
| operating supply voltage | 5 V to 12 V |
| operating supply voltage: | 5 V to 12 V |
| operating temperature | -40В°C ~ 85В°C |
| output current per channel | 175 mA |
| output current per channel: | 175 mA |
| package | Tube |
| package / case | 8-SOIC (0.154"", 3.90mm Width) |
| package / case: | SOIC-8 |
| package height | 1.5(Max) |
| package length | 5(Max) |
| package width | 4(Max) |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8012208857 |
| part status | active |
| pcb changed | 8 |
| pd - power dissipation | 750 mW |
| pd - power dissipation: | 750 mW |
| pin count | 8 |
| power supply type | Dual|Single |
| product | Operational Amplifiers |
| product: | Operational Amplifiers |
| product category | High Speed Operational Amplifiers |
| product category: | High Speed Operational Amplifiers |
| product type: | Op Amps-High Speed Operational Amplifiers |
| psrr - power supply rejection ratio | 70 dB |
| psrr - power supply rejection ratio: | 70 dB |
| reach status | REACH Unaffected |
| rohs | Details |
| rohs status | ROHS3 Compliant |
| series | AD8009 |
| series: | AD8009 |
| settling time | 10ns |
| settling time: | 10 ns |
| shutdown | No Shutdown |
| shutdown: | No Shutdown |
| shut down support | No |
| slew rate | 5500V/Вµs |
| sr - slew rate | 5500 V/us |
| sr - slew rate: | 5.5 kV/us |
| standard package name | SOP |
| subcategory: | Amplifier ICs |
| supplier device package | 8-SOIC |
| supplier package | SOIC N |
| supplier temperature grade | Industrial |
| supply type | Single, Dual |
| supply type: | Single, Dual |
| supply voltage - max | 12 V |
| supply voltage - max: | 12 V |
| supply voltage - min | 5 V |
| supply voltage - min: | 5 V |
| topology | Current Feedback |
| topology: | Current Feedback |
| type | High Speed Amplifier |
| typical dual supply voltage (v) | ±3|±5 |
| typical input bias current (ua) | 50@5V |
| typical input noise voltage density (nv/rthz) | 1.9@5V |
| typical inverting input current noise density (pa/rthz) | 41@5V |
| typical noninverting input current noise density (pa/rthz) | 46@5V |
| typical output current (ma) | 175@5V |
| typical settling time (ns) | 25 |
| typical single supply voltage (v) | 9 |
| typical slew rate (v/us) | 2100@5V |
| unit weight | 0.019048 oz |
| вес, г | 0.174 |
| voltage gain db | 108 dB |
| voltage gain db: | 108 dB |
| voltage - input offset | 2mV |
| voltage - supply, single/dual (в±) | 5V ~ 12V, В±2.5V ~ 6V |
| vos - input offset voltage | 2 mV |
| vos - input offset voltage: | 2 mV |
| width | 4 mm |
| -3db bandwidth | 1GHz |
