CD4082BE, Logic Gates Dual 4-Input
Оставить отзыв
В избранноеВ сравнение
Артикул: CD4082BE
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
Semiconductors\Logic ICs\Logic GatesAND Gate IC 2 Channel 14-PDIP
| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 09.06.2024 |
| Время загрузки | 1:50:56 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| absolute propagation delay time (ns) | 250 |
| automotive | No |
| base product number | CD4082 -> |
| current - output high, low | 3.4mA, 3.4mA |
| current - quiescent (max) | 1ВµA |
| eccn | EAR99 |
| eccn (us) | ear99 |
| eu rohs | compliant |
| factory pack quantity | 25 |
| factory pack quantity: factory pack quantity: | 25 |
| function | AND |
| function: | Dual 4-Input |
| height | 4.57 mm |
| high level output current | -1.5 mA |
| high level output current: | -6.8 mA |
| htsus | 8542.39.0001 |
| input type | CMOS |
| input type: | CMOS |
| категория | Электронные компоненты/Микросхемы |
| lead shape | Through Hole |
| length | 19.3 mm |
| logic family | CD4000 |
| logic family: | CD4000 |
| logic function | AND |
| logic function: | AND |
| logic level - high | 3.5V ~ 11V |
| logic level - low | 1.5V ~ 4V |
| logic type | AND Gate |
| logic type: | 4-Input AND |
| low level output current | 1.5 mA |
| low level output current: | 6.8 mA |
| manufacturer | Texas Instruments |
| manufacturer: | Texas Instruments |
| maximum high level output current (ma) | -4.2(Min) |
| maximum low level output current (ma) | 4.2(Min) |
| maximum operating supply voltage (v) | 18 |
| maximum operating temperature | +125 C |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum propagation delay time @ maximum cl (ns) | 250@5V|120@10V|90@15V |
| maximum quiescent current (ua) | 5 |
| max propagation delay @ v, max cl | 90ns @ 15V, 50pF |
| minimum operating supply voltage (v) | 3 |
| minimum operating temperature | -55 C |
| minimum operating temperature: | -55 C |
| minimum operating temperature (°c) | -55 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting | Through Hole |
| mounting style | Through Hole |
| mounting style: | Through Hole |
| mounting type | Through Hole |
| number of bits | 2 bit |
| number of bits: | 2 bit |
| number of circuits | 2 |
| number of elements | 2 |
| number of elements per chip | 2 |
| number of element inputs | 4-IN |
| number of element outputs | 1 |
| number of gates | 2 Gate |
| number of gates: | 2 Gate |
| number of inputs | 4 |
| number of inputs/bits per element | 4 |
| number of inputs per gate | 4 |
| number of input lines | 4 Input |
| number of input lines: | 8 Input |
| number of output enables per element | 0 |
| number of output lines | 1 Output |
| number of output lines: | 2 Output |
| number of selection inputs per element | 0 |
| operating supply current | 15 uA |
| operating supply current: | 15 uA |
| operating supply voltage | 3V ~ 18V |
| operating supply voltage: | 10 V |
| operating temperature | -55В°C ~ 125В°C |
| operating temperature range | -55 C to+125 C |
| operating temperature range: | -55 C to+125 C |
| output type | CMOS |
| output type: | CMOS |
| package | Tube |
| package / case | 14-DIP (0.300"", 7.62mm) |
| package / case: | PDIP-14 |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8004995944 |
| part status | active |
| pcb changed | 14 |
| pin count | 14 |
| ppap | No |
| process technology | CMOS |
| product | Single-Function Gate |
| product: | Single-Function Gate |
| product category | Logic Gates |
| product category: | Logic Gates |
| product type: | Logic Gates |
| propagation delay test condition (pf) | 50 |
| propagation delay time | 120 ns |
| propagation delay time: | 60 ns |
| quiescent current | 20 nA |
| quiescent current: | 20 nA |
| reach status | REACH Unaffected |
| rohs | Detailsabyzqfztrtuatfwseuyxszddc |
| rohs status | ROHS3 Compliant |
| schmitt trigger input | No |
| series | 4000B -> |
| series: | CD4082B |
| standard package name | DIP |
| subcategory: | Logic ICs |
| supplier device package | 14-PDIP |
| supplier package | PDIP |
| supply voltage - max | 18 V |
| supply voltage - max: | 18 V |
| supply voltage - min | 3 V |
| supply voltage - min: | 3 V |
| typical operating supply voltage (v) | 3.3|5|9|12|15 |
| typical quiescent current (ua) | 0.02 |
| unit weight | 0.032734 oz |
| вес, г | 0.93 |
| voltage - supply | 3V ~ 18V |
