| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 07.07.2023 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| absolute propagation delay time (ns) | 17.05.2023 |
| base product number | 74AHC573 -> |
| bus hold | NO |
| circuit | 8:08:00 |
| current - output high, low | 8mA, 8mA |
| delay time - propagation | 1ns |
| eccn | EAR99 |
| eccn (us) | ear99 |
| eu rohs | compliant |
| factory pack quantity | 25 |
| factory pack quantity: factory pack quantity: | 25 |
| function | 3-State Octal D-Type |
| function: | 3-State Octal D-Type |
| height | 2.35 mm |
| high level output current | -8 mA |
| high level output current: | -8 mA |
| hts | 8542.39.00.01 |
| htsus | 8542.39.0001 |
| independent circuits | 1 |
| категория | Электронные компоненты/Микросхемы |
| latch mode | Transparent |
| lead shape | Gull-wing |
| length | 12.8 mm |
| logic family | 74AHC |
| logic family: | 74AHC |
| logic type | Transparent D-Type Latch |
| logic type: | ИСТИНА |
| low level output current | 32 mA |
| low level output current: | 32 mA |
| manufacturer | Texas Instruments |
| manufacturer: | Texas Instruments |
| maximum high level output current (ma) | -8 |
| maximum low level output current (ma) | 8 |
| maximum operating supply voltage (v) | 05.05.2023 |
| maximum operating temperature | +85 C |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum propagation delay time @ maximum cl (ns) | 14.5@3.3V|8.8@5V |
| maximum quiescent current (ua) | 4 |
| minimum operating supply voltage (v) | 2 |
| minimum operating temperature | -40 C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting | surface mount |
| mounting style | SMD/SMT |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels | 8 Channels |
| number of channels: | 8 Channels |
| number of channels per chip | 8 |
| number of circuits | 8 Circuit |
| number of circuits: | 8 |
| number of elements per chip | 1 |
| number of inputs per chip | 8 |
| number of input enables per element | 1 |
| number of input lines | 3 Line |
| number of input lines: | 3 Line |
| number of outputs per chip | 8 |
| number of output enables per element | 1 |
| number of output lines | 1 Line |
| number of output lines: | 1 Line |
| number of selection inputs per element | 0 |
| operating supply voltage | 2 V to 5.5 V |
| operating supply voltage: | 2 V to 5.5 V |
| operating temperature | -40В°C ~ 85В°C |
| output type | 3-State |
| output type: | 3-State |
| package | Tube |
| package / case | SOIC-20 |
| package / case: | SOIC-20 |
| package height | 2.35(Max) |
| package length | 13(Max) |
| package width | 7.6(Max) |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8002948473 |
| part status | active |
| pcb changed | 20 |
| pin count | 20 |
| polarity | Non-Inverting |
| polarity: | Non-Inverting |
| process technology | CMOS |
| product category | Latches |
| product category: | Latches |
| product type: | Latches |
| propagation delay test condition (pf) | 50 |
| propagation delay time | 14.5 ns at 3.3 V, 8.8 ns at 5 V |
| propagation delay time: | 14.5 ns, 8.8 ns |
| quiescent current | 4 uA |
| quiescent current: | 4 uA |
| reach status | REACH Unaffected |
| reset type | No Reset |
| reset type: | No Reset |
| rohs | Details |
| rohs status | ROHS3 Compliant |
| series | SN74AHC573 |
| series: | SN74AHC573 |
| set/reset | NO |
| standard package name | SOP |
| subcategory: | Logic ICs |
| supplier device package | 20-SOIC |
| supplier package | SOIC |
| supplier temperature grade | Commercial |
| supply voltage - max | 5.5 V |
| supply voltage - max: | 5.5 V |
| supply voltage - min | 2 V |
| supply voltage - min: | 2 V |
| tolerant i/os (v) | 5 Inputs |
| type | D-Type |
| type: | D-Type |
| typical operating supply voltage (v) | 2.5|3.3|5 |
| unit weight | 0.017662 oz |
| вес, г | 1.16 |
| voltage - supply | 2V ~ 5.5V |
| width | 7.52 mm |
