| Информация о производителе | |
| Производитель | Texas Instruments |
| Основные | |
| Дата загрузки | 09.07.2023 |
| Время загрузки | 15:41:45 |
| Бренд | Texas Instruments |
| Вес и габариты | |
| base product number | TLC372 -> |
| current - input bias (max) | 5pA @ 5V |
| current - output (typ) | 20mA |
| current - quiescent (max) | 400ВµA |
| диапазон напряжения питания | 3В до 16В |
| eccn | EAR99 |
| eccn (us) | ear99 |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 750 |
| hts | 8542.39.00.01 |
| htsus | 8542.39.0001 |
| ib - input bias current: | 5 pA |
| input type: | Differential |
| ios - input offset current: | 1 pA |
| категория | Электронные компоненты/Микросхемы |
| количество выводов | 8вывод(-ов) |
| lead shape | Gull-wing |
| максимальная рабочая температура | 70°C |
| manufacturer: | Texas Instruments |
| manufacturer type | Differential Comparator |
| maximum dual supply voltage (v) | ±8 |
| maximum input bias current (ua) | 0.000005(Typ)@5V |
| maximum input offset voltage (mv) | 5@5V |
| maximum operating supply voltage (v) | ±8|16 |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 70 |
| maximum propagation delay time (ns) | 200(Typ) |
| maximum quiescent current (ma) | 0.3@5V |
| maximum single supply voltage (v) | 16 |
| минимальная рабочая температура | 0°C |
| minimum dual supply voltage: | 1.5 V |
| minimum dual supply voltage (v) | ±1.5 |
| minimum operating temperature: | -55 C |
| minimum operating temperature (°c) | 0 |
| minimum single supply voltage (v) | 3 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels: | 2 Channel |
| number of channels per chip | 2 |
| number of elements | 2 |
| operating supply current: | 150 uA |
| operating supply voltage: | 3 V to 16 V |
| operating temperature | 0В°C ~ 70В°C |
| output current per channel: | 6 mA |
| output type | Open Drain/Collector |
| output type: | CMOS, TTL |
| package | Tube |
| package / case | 8-TSSOP (0.173"", 4.40mm Width) |
| package / case: | TSSOP-8 |
| package height | 1.05(Max) |
| package length | 3.1(Max) |
| package width | 4.5(Max) |
| packaging | Tube |
| packaging: | Tube |
| партномер | 8002686741 |
| part status | active |
| pcb changed | 8 |
| pin count | 8 |
| power supply type | Single|Dual |
| process technology | LinCMOS |
| product: | Analog Comparators |
| product category: | Analog Comparators |
| product type: | Analog Comparators |
| rail to rail | Rail to Rail Output |
| reach status | REACH Unaffected |
| reference voltage: | No |
| response time: | 650 ns |
| rohs status | ROHS3 Compliant |
| series | LinCMOSв„ў -> |
| series: | TLC372 |
| shutdown: | No Shutdown |
| standard package name | SOP |
| subcategory: | Amplifier ICs |
| supplier device package | 8-TSSOP |
| supplier package | TSSOP |
| supply voltage - max: | 16 V |
| supply voltage - min: | 3 V |
| тип компаратора | Дифференциальный |
| тип выхода микросхемы | Открытый Коллектор, Сток |
| type | Differential |
| typical dual supply voltage (v) | ±3|±5 |
| typical output current (ma) | 20(Max) |
| typical response time (us) | 0.65 |
| typical single supply voltage (v) | 5|9|12|15 |
| уровень чувствительности к влажности (msl) | MSL 1-Безлимитный |
| вес, г | 0.4 |
| voltage - input offset (max) | 5mV @ 5V |
| voltage - supply, single/dual (в±) | 3V ~ 16V, В±1.5V ~ 8V |
| vos - input offset voltage: | 5 mV |
| время реакции | 200нс |
