| Информация о производителе | |
| Производитель | Microchip Technology |
| Основные | |
| Дата загрузки | 09.07.2023 |
| Время загрузки | 15:42:57 |
| Бренд | Microchip Technology |
| Вес и габариты | |
| automotive | Yes |
| common mode rejection ratio | 70(dB) |
| comparator type | General Purpose |
| диапазон напряжения питания | 1.8В до 5.5В |
| dual supply voltage (max) | Not Required(V) |
| dual supply voltage (min) | Not Required(V) |
| dual supply voltage (typ) | Not Required(V) |
| eccn (us) | ear99 |
| eu rohs | compliant |
| factory pack quantity: factory pack quantity: | 3000 |
| high level output current: | -100 nA |
| ib - input bias current: | 1 pA |
| input offset voltage | 10(mV) |
| категория | Электронные компоненты/Микросхемы |
| количество выводов | 6вывод(-ов) |
| lead shape | Gull-wing |
| линейка продукции | - |
| максимальная рабочая температура | 125°C |
| manufacturer: | Microchip |
| manufacturer type | General Purpose Comparator |
| maximum input bias current (ua) | 0.000001(Typ)@5.5V |
| maximum input offset voltage (mv) | 10@5.5V |
| maximum operating supply voltage (v) | 05.05.2023 |
| maximum operating temperature | +125 °C |
| maximum operating temperature: | +125 C |
| maximum operating temperature (°c) | 125 |
| maximum propagation delay time (ns) | 8000 |
| maximum quiescent current (ma) | 0.004@5.5V |
| maximum single supply voltage (v) | 05.05.2023 |
| минимальная рабочая температура | -40°C |
| minimum operating temperature | -40 °C |
| minimum operating temperature: | -40 C |
| minimum operating temperature (°c) | -40 |
| minimum single supply voltage (v) | 01.08.2023 |
| mounting | surface mount |
| mounting style: | SMD/SMT |
| mounting type | Surface Mount |
| number of channels: | 1 Channel |
| number of channels per chip | 1 |
| number of elements | 1 |
| operating supply current: | 2.5 uA |
| operating temperature classification | Automotive |
| operating temp range | -40C to 125C |
| output current per channel: | 50 mA |
| output type | Open Drain |
| output type: | Open Drain |
| package / case: | SOT-23-6 |
| package type | SOT-23 |
| packaging | Tape and Reel |
| packaging: | Reel, Cut Tape, MouseReel |
| партномер | 8005459681 |
| part status | active |
| pcb changed | 6 |
| pin count | 6 |
| power supply rejection ratio | 80(dB) |
| power supply requirement | Single |
| power supply type | Single |
| ppap | Yes |
| process technology | CMOS |
| product: | Analog Comparators |
| product category: | Analog Comparators |
| product type: | Analog Comparators |
| propagation delay time: | 4 us |
| qualification: | AEC-Q100 |
| rad hardened | No |
| rail to rail | Rail to Rail Input |
| response time: | 4 us |
| single supply voltage (max) | 5.5(V) |
| single supply voltage (min) | 1.8(V) |
| single supply voltage (typ) | 3/5(V) |
| standard package name | SOT |
| subcategory: | Amplifier ICs |
| supplier package | SOT-23 |
| supply voltage - max: | 5.5 V |
| supply voltage - min: | 1.8 V |
| technology | CMOS |
| тип компаратора | Низкая Мощность |
| typical output current (ma) | 50(Max) |
| typical single supply voltage | 1.8 → 5.5 V |
| уровень чувствительности к влажности (msl) | MSL 1-Безлимитный |
| вес, г | 0.04 |
| vos - input offset voltage: | 10 mV |
| время реакции | 4мкс |
| width | 1.8mm |
