Precison Fixed and Adjustable Voltage Reference ICs utilsing series, shunt or series/shunt topologies and available in both through-hole and surface mount packages.
Информация о производителе
Производитель
Texas Instruments
Основные
Дата загрузки
30.04.2024
Время загрузки
1:02:24
Бренд
Texas Instruments
Вес и габариты
automotive
No
eccn (us)
EAR99
eu rohs
Compliant
initial accuracy
1%
категория
Электронные компоненты/Микросхемы
lead shape
Gull-wing
load regulation
2 mV
maximum operating temperature
85В°C(TA)
maximum operating temperature (°c)
85
maximum output current
12mA
maximum output current (ma)
12
maximum output voltage
10 V
maximum temperature coefficient
20ppm/°C(Typ)
minimum operating temperature
-40В°C
minimum operating temperature (°c)
-40
minimum output voltage
1.24 V
mounting
Surface Mount
mounting type
Surface Mount
nominal voltage
1.233-10V
output current
12mA
output type
Adjustable
output voltage
1.233V
output voltage (v)
1.24 to 10
package type
SOT-23
packaging
Tape and Reel
партномер
8006439262
part status
Active
pcb changed
3
pin count
3
ppap
No
reference type
Shunt
shunt current - min
70uA
standard package name
SOT
supplier package
SOT-23
supplier temperature grade
Industrial
temperature coefficient
150ppm/В°C
tolerance
В±1%
topology
SHUNT
voltage - output (max)
10V
width
1.3mm
