MP6526GY-Z, Motor Driver/Controller, Half Bridge, 5 Outputs, 7 V to 28 V Supply, 900 mA Output, SOIC-28

Полупроводники - Микросхемы\Микросхемы Управления Питанием\Драйверы и Контроллеры\Контроллеры / Приводы ДвигателейThe MP6526 is a six-half-bridge, DMOS, output driver with integrated power MOSFETs that can drive up to six different loads. The six half-bridges can be controlled separately from a standard serial data interface and have various diagnostic functions. The MP6526 has very low quiescent current in standby mode, making it suitable for a wide range of applications. Full protection features include short-circuit protection (SCP), under-voltage protection (UVP) and thermal shutdown. • RDS(ON) (HS + LS) typically 1.1ohm at 25°C, maximum 2ohm at 150°C• Very low quiescent current IVS < 6µA in standby mode versus total temperature range• Over-temperature protection and prewarning• Serial data interface• Shorted output, open-load, over-temperature and under-voltage• Fault output flag• Serial interface clock frequency up to 3MHz, 5V compatible
