DG442DJ-E3, IC: аналоговый переключатель; SPST-NO; Ch: 4; DIP16; -15?15В; туба
Оставить отзыв
В избранноеВ сравнение
Артикул: DG442DJ-E3
- Обзор
- Характеристики
- Отзывы (0)
- Реквизиты
4 Circuit IC Switch 1:1 85Ohm 16-DIP
| Основные | |
| вес, г | 1 |
| moisture sensitivity level (msl) | 1 (Unlimited) |
| mounting type | Through Hole |
| operating temperature | -40В°C ~ 85В°C (TA) |
| package | Tube |
| package / case | 16-DIP (0.300"", 7.62mm) |
| rohs status | ROHS3 Compliant |
| type | Analog Switch |
| eccn | EAR99 |
| htsus | 8542.39.0001 |
| supplier device package | 16-DIP |
| pin count | 16 |
| eu rohs | compliant |
| lead shape | Through Hole |
| maximum operating temperature (°c) | 85 |
| mounting | Through Hole |
| part status | active |
| pcb changed | 16 |
| standard package name | DIP |
| supplier package | PDIP |
| base product number | DG442 -> |
| eccn (us) | ear99 |
| maximum dual supply voltage (v) | ±22 |
| maximum power dissipation (mw) | 450 |
| minimum dual supply voltage (v) | ±7 |
| minimum operating temperature (°c) | -40 |
| configuration | Quad SPST |
| power supply type | Single|Dual |
| maximum single supply voltage (v) | 36 |
| minimum single supply voltage (v) | 13 |
| number of outputs per chip | 4 |
| typical dual supply voltage (v) | ±12|±15|±9|±18 |
| typical single supply voltage (v) | 24|15|28|18 |
| hts | 8542.39.00.01 |
| polarity | Non-Inverting |
| package height | 3.81(Max) |
| package length | 21.33(Max) |
| package width | 7.11(Max) |
| maximum supply current (ma) | 0.1@16.5V@-40C to 85C/-0.001@-16.5V |
| Вес и габариты | |
| input signal type | Single |
| maximum high level output current (ma) | 30 |
| number of circuits | 4 |
| number of inputs per chip | 4 |
| number of channels per chip | 4 |
| chip enable signals | Yes |
| on-state resistance (max) | 85Ohm |
| output signal type | Single |
| typical supply current (ma) | 0.015@16.5V@-40C to 85C/-0.0000001@-16.5V |
| channel capacitance (cs(off), cd(off)) | 4pF, 4pF |
| channel-to-channel matching (δron) | 4Ohm (Max) |
| charge injection | -1pC |
| crosstalk | -100dB @ 1MHz |
| current - leakage (is(off)) (max) | 500pA |
| multiplexer/demultiplexer circuit | 1:1 |
| switch circuit | SPST - NO |
| switch time (ton, toff) (max) | 250ns, 210ns |
| voltage - supply, dual (vв±) | В±15V |
| voltage - supply, single (v+) | 12V |
| maximum on resistance (ohm) | 160@10.8V |
| maximum on resistance range (ohm) | 150 to 250 |
| maximum turn-off time (ns) | 210@±15V |
| maximum turn-on time (ns) | 450@12V |
| switch architecture | SPST |
